Артикул
Название
Примечание
Количество
1
488239R91
HOPPER ASSY
2шт.
17433R1
HARDWARE,Hex, 1/2" - 13 x 1", Gr 2
BOLT, 1/2-13 x 1 C-Z hex-hd mach
8шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
8шт.
120384
WASHER,1/2"
LOCK, 1/2"
8шт.
2
472400R2
DIVIDER, fertilizer hopper center, 1 per hopper
1шт.
3
624456R1
CLIP, lid spring
4шт.
4
484050R1
COVER ASSY, hopper
2шт.
12235R1
PIN, 1/8 x 3/8 C-Z cotter 1/8" x 5/8"
4шт.
5
479124R1
VALVE SPRING
SPRING, hopper hold down
4шт.
6
472416R2
HOUSING
auger feed
4шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd
16шт.
120376
NUT,5/16"-18, G5
16шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
16шт.
134238R1
WASHER
11/32 x 1 x 16 ga C-Z16
16шт.
7
487039R1
FRAME ASSY, main
1шт.
18707R1
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2
BOLT, 1/2 x 1 C-Z sq-nk crg
12шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
12шт.
120384
WASHER,1/2"
LOCK, 1/2"
12шт.
432695R1
BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 8
5/8 x 1-3/4 C-Z hex-hd mach
4шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
4шт.
8
484051R1
ROD, tie
4шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
16шт.
120384
WASHER,1/2"
LOCK, 1/2"
8шт.
9
487042R1
ANGLE, hopper tie
2шт.
427566
BOLT,Hex, 1/2"-13 x 1 1/2", G8, Full Thd
1/2 x 1-1/2 C-Z hex-hd mach
2шт.
20534R1
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 8
1/2 x 1-3/4 C-Z hex-hd mach
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
4шт.
120384
WASHER,1/2"
LOCK, 1/2"
4шт.
460908R1
WASHER
17/32 x 1-1/2 x 11 ga C-Z
2шт.
10
472429R1
BAR
WASHER, hopper reinforcing
8шт.
11
480099R2
HOUSING
auger feed center
2шт.
12872R1
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd
8шт.
120376
NUT,5/16"-18, G5
8шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
8шт.
134238R1
WASHER
11/32 x 1 x 16 ga C-Z
8шт.
12
484279R1
COVER, hopper opening
4шт.
18473R1
SCREW,Hex, 5/16"-18 X 5/8", G2
BOLT, 5/16 x 5/8 C-Z hex-hd mach
16шт.
120376
NUT,5/16"-18, G5
16шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
16шт.
134238R1
WASHER
11/32 x 1 x 16 ga C-Z
16шт.
13
480100R1
WASHER
housing plug, 4 for four row
1шт.
18767R1
BOLT,Hex, 5/16"-18 x 2", G2
5/16 x 2 C-Z hex-hd mach
2шт.
120376
NUT,5/16"-18, G5
2шт.
14
(Not used in this application)
1шт.
15
472417R1
BEARING
auger
4шт.
16
484278R2
BAR
auger feed
2шт.
21650R1
LOCK PIN,5/16" x 2 1/2", Slotted
Pin, 5/16" x 2 1/2", Slotted
2шт.
187988
COTTER PIN,3/16" x 1 1/4"
PIN, SPLIT (COTTER), 3/16" x 1 1/4"
16шт.
Выбрано товаров: 49
