Запчасти Case IH 4765 (77.100.XX[05]) - MANUAL CONTROL AUGER MOUNTS 350 TOW BEHIND BUSHEL (77) - SEEDING/PLANTING

1

47747646

MOUNT

Manual Auger Black

1шт.

2

47748216

ARM

Auger Inner

1шт.

3

47839650

SUPPORT

Auger T

1шт.

4

47744264

MOUNT

Auger Latch

1шт.

5

47744269

PLATE

Mounting Auger Latch

1шт.

6

47744272

SUPPORT

Front Auger Saddle

1шт.

7

47744197

SUPPORT

Rear Auger

1шт.

8

381928

ROLL PIN,10mm OD x 50mm L, Slotted

2шт.

9

23261

WASHER

1.515 ID

2шт.

10

47748656

ROD

Auger Arm

1шт.

11

43168

BOLT,Hex, M16 x 40mm, Cl 8.8

2шт.

12

323866

BOLT,Hex, M16 x 2.0 x 60mm, Cl 8.8

4шт.

13

120090

BOLT,Hex, M16 x 50mm, Cl 8.8

4шт.

14

382358

BOLT,Hex, M16 x 2 x 200mm, Cl 8.8

4шт.

15

146988

LOCK NUT,M16 x 2, Cl 8

14шт.

16

9706717

BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8

2шт.

17

100038

NUT,M12 x 1.75, Cl 8

2шт.

18

84557601

PIN,31.75mm OD x 442mm L

1шт.

19

86518210

BOLT,Hex, M14 x 75mm, Cl 8.8

1шт.

20

412370

NUT,M14 x 2, Cl 8

1шт.

21

84583373

SUPPORT

Hose Guide

1шт.

22

87020818

LOCK PIN,1/4" OD x 2" OAL, Slotted

1шт.

23

130078

LOCK PIN,M4 x 30, Slotted

1шт.

24

87505486

COIL SPRING

Pin

1шт.

25

47839837

LUG

Auger Pivot Service

1шт.

26

86624086

PIN,5/8" x 3", Coiled

1шт.
