Запчасти Case IH 3430 (75.100.12) - MECHANICAL DRIVE - ON FRAME - DRIVE BOXES (3 TANK) (75) - SOIL PREPARATION

Схема запчастей Case IH 3430 - (75.100.12) - MECHANICAL DRIVE - ON FRAME - DRIVE BOXES (3 TANK) (75) - SOIL PREPARATION
10
18
24
15
23
32
29
11
7
14
9
13
34
13
11
13
3
35
14
33
4
37
17
7
1
13
16
6
28
5
25
2
20
36
19
8
14
21
9
28
12
39
9
17
14
14
22
13
30
4
38
75.100.15
18
14
18
7
31
2
2

Артикул

Название

Примечание

Количество

1

427-8175

CLEVIS PIN,1/2" x 1 3/4'"

3шт.

2

88011

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

20шт.

3

20304

BOLT,Hex, 3/8" - 16 x 5 1/2", Gr 5

3шт.

4

87670

BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5

3шт.

5

9706716

BOLT,Hex, 1/2" - 13 x 2", Gr 5

4шт.

6

87972

BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 5

2шт.

7

280431

NUT,1/2"-13, G5

12шт.

8

281010

LOCK NUT,7/8"-14, GC

5шт.

9

86992215

LOCK NUT,1/2"-13, GC

4шт.

10

81547

LOCK WASHER,7/16"

6шт.

11

80679

LOCK WASHER,1/20.507 CST ZND

5шт.

12

95-21031

WASHER,1/4"

1шт.

13

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

49шт.

14

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

14шт.

15

300868

ROLL PIN,6mm OD x 36mm L, Slotted

1шт.

16

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5шт.

17

2244

SPROCKET

idler

5шт.

18

9628503

NUT,3/8"-16, G5

24шт.

19

5868

WASHER,0.5" ID x 1" OD x 0.06" Thk

1/2" id 1" 16ga

1шт.

20

38-11010

LOCK PIN,5/32" x 5/8", Slotted

3шт.

21

7087

BOLT

3/8"-16 x 7", G5, 2 1/2" thread

3шт.

22

9439

BOLT

1/2"-13 x 2 1/2" G2 all thread

1шт.

23

87506268

COIL SPRING

1/16" wire x 3/4" od x 2 1/2" long

1шт.

24

425286A1

SPECIAL WRENCH

1/2'' combination

1шт.

25

425287A1

SPECIAL WRENCH

3/4'' combination

1шт.

28

GL-319

PLATE

mounting outer

3шт.

29

GL-327

SPACER

idler sprocket

1шт.

30

GL-329

SHIELD

flip up

1шт.

31

GL-361

BRACKET

front idler mechanical drive

1шт.

32

GL-376

BRACKET

shield lock down

1шт.

33

GL-377

LOCKING DEVICE

shield - mechanical drive

1шт.

34

GL-486

BRACKET

flip up shield mechanical drive

2шт.

35

GL-488

BRACKET

shield brace

1шт.

36

GL-489

SUPPORT

shield lift

1шт.

37

GL-732A

TRANSFER BOX

meter drive assembly

3шт.

Refer to 75.100.15

1шт.

38

GM-278

PLATE

mounting inner - mechanical drive

3шт.

39

GM-333

BRACKET

wrench holder

1шт.

Выбрано товаров: 38
