Артикул
Название
Примечание
Количество
2
87501237
CROSSBAR
mount, top
1шт.
3
280161
BOLT,Hex, 3/8" - 16 x 3", Gr 5
3шт.
4
RF-240
TRAY
hose
1шт.
5
87501490
CLAMP
hose tray
1шт.
6
88421
BOLT,Hex, 3/4" - 10 x 5", Gr 5
1шт.
7
87501450
BRACKET
mount, rear hose tray
1шт.
8
88902
NUT,3/8"-16
3шт.
9
88011
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3шт.
10
GE-293A
HITCH PIN
draw assembly
1шт.
Includes linch pin and roll pin
1шт.
Includes GE-293, 6425 and 86544809
1шт.
11
6425
LINCH PIN
7/16" x 1 3/8"
1шт.
12
280375
NUT,3/4"-10, GC
1шт.
14
GL-731
RAIL ASSY.
hitch RH
1шт.
16
GH-745
HITCH
rail LH
1шт.
17
1344524C1
U-BOLT
us 1/2" x 2 9/18" w x 3 1/2" d 1" thread
1шт.
18
GH-528
MOUNTING PLATE
hitch support
1шт.
19
GH-530
BRACKET
mount, fan shield chain
1шт.
20
412752A1
PIN
and chain assembly jack mount
1шт.
21
86992215
LOCK NUT,1/2"-13, GC
1шт.
22
GE-359
STAND
field hitch - upper
1шт.
23
GE-193A
HANDLE
height adjustment
1шт.
Includes GE-193 and 6270
1шт.
24
GE-358
STAND
field hitch - lower
1шт.
25
80755
COTTER PIN,1/8" OD x 1" L
1шт.
26
86505993
BOLT,Hex, 1/2" - 13 x 4", Gr 5
1шт.
27
GH-525
SUPPORT
cross field hitch
1шт.
28
87501455
BRACKET
mount, hose tray
1шт.
29
87501485
SPACER
hose tray
1шт.
30
87501453
CLAMP
front hose tray
1шт.
31
88604
BOLT,Hex, 7/16" - 14 x 2 1/2", Gr 5
1шт.
32
280980
NUT,7/16"-14, GC
1шт.
33
81547
LOCK WASHER,7/16"
1шт.
34
280717
NUT,7/16"-14, G5
1шт.
35
86992286
HOSE,2.50" ID x 100.00'
Spiral PVC Black Order Multiples of 100 Feet
1шт.
36
214-1444
HOSE CLAMP,58.6mm - 82.5mm
1шт.
37
GD-673
FITTING
hose connector 2 1/2"
1шт.
38
6177
OIL SEAL
quick connect 2 1/2" id
1шт.
40
GD-254
COVER
plate hose connect
1шт.
41
6425
LINCH PIN
7/16" x 1 3/8"
1шт.
42
412768A1
HITCH PIN
1" x 2 3/4" usable
1шт.
Includes 6425
1шт.
43
GE-197
LINKAGE,Uses 1 each of 1" and 3/4" pins
mount, pivot link
1шт.
44
412769A1
HITCH PIN
1" x 3 1/2" usable
1шт.
Includes 6425
1шт.
45
9706701
BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5
1шт.
46
85700693
NUT,5/8" - 11, Gr C
1шт.
46
280375
NUT,3/4"-10, GC
1шт.
47
GE-196.2
BRACKET
mount
1шт.
48
3951
U-BOLT
us 5/8"-11 4 1/16" w 5 3/8" d GR5
1шт.
48
7818
U-BOLT
us 3/4"-10 x 4 1/32" wide x 5 5/8" deep
1шт.
50
86632557
JAM NUT,Jam, 3/4"-10, G5
1шт.
51
88007
BOLT,Hex, 3/4" - 10 x 4 1/2", Gr 5
1шт.
52
5089
U-BOLT
us 7/16"-14 4 1/8" w 5 3/8" d GR2
1шт.
53
GD-671
SUPPORT
connector
1шт.
54
GE-186
SUPPORT
hydraulic couplers & wiring harness bracket
1шт.
55
GD-672A
HOLDER
quick connect 2 1/2" female
1шт.
Includes two 88011, four 87016560, two 5625 and four 4630
1шт.
56
88206
BOLT,Hex, 3/8" - 16 x 1", Gr 5
1шт.
57
6935
COUPLING, QUICK, FEM
3/4"
1шт.
58
80680
LOCK WASHER,3/8 0.381 CST ZND
1шт.
60
9628503
NUT,3/8"-16, G5
1шт.
61
GH-139
BRACKET
plug support
1шт.
65
GE-202
CLAMP
for two 3/4" couplers
1шт.
67
6934
PLUG
dust, pioneer coupler - 3/4"
1шт.
68
87657
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
1шт.
70
3236
SELF-TAP SCREW
1/4"-20 x 1 1/4" oh pi plt
1шт.
71
280129
NUT,1/4"-20
1шт.
72
9706729
BOLT,Hex, 7/16" - 14 x 1", Gr 5, Full Thd
1шт.
73
1994568C1
COUPLING, QUICK, FEM
1/2" fpt
1шт.
74
GH-601
COUPLING
hydraulic mount third line
1шт.
75
1569
U-BOLT
ur 5/16" x 1 3/8" w x 2 1/16" d 3/4" thread
1шт.
76
8679
PLUG
dust, pioneer coupler - 3/8"
1шт.
77
80681
LOCK WASHER,5/16"
1шт.
78
9635082
NUT,5/16" - 18, Gr 5
1шт.
79
21560
HYDRAULIC HOSE,19.05mm ID x 12319mm L, SAE 100R17
3/4" x 485" fl, 1/2" mpt x 3/4" mpt
2шт.
For the STX / TJ tractors
1шт.
80
87500095
HYDRAULIC HOSE,19mm ID x 12319mm L
3/4" x 485" fl, 1/2" mpt x 1/2" mpt
1шт.
Fan third line
1шт.
100
GE-518K
HOSE KIT
hose - 2 1/2"
1шт.
Includes splice tube GE-518 and two 214-1444 hose clamps
1шт.
Not Shown
1шт.
Выбрано товаров: 84
