Артикул
Название
Примечание
Количество
1
1016213
TOGGLE
WLDMT - toggle
1шт.
2
1016220
COVER ASSY
ASSY - cover & wiper: front Incl 3-9
1шт.
3
1016217
COVER ASSY
WLDMT - cover front
1шт.
4
1018874
GASKET
- door: side
1шт.
5
1030985
SEAL
WIPER - rubber
1шт.
6
1030984
WIPER
- support
1шт.
7
1032058
SCREW
- F-H-S-C: .19 x .50 NC SS
5шт.
8
1032060
WASHER,0.2" ID x 0.44" OD x 0.04" Thk
- flat: .19 SS
1шт.
9
1032059
LOCK NUT
NUT - K-Lock: 18-8 SS .19 NC
1шт.
10
1013920
SHAFT
- roll drive
1шт.
11
METERING ROLLS (See metering rolls parts page)
1шт.
12
1017768
DEFLECTOR
ASSY - seed deflector: front
1шт.
13
1032095
SCREW
- F-H-S-C: .19 x .625 NC SS
4шт.
14
1012955
DEFLECTOR
WLDMT - plate deflector
1шт.
15
1013128
DEFLECTOR
- rubber
1шт.
16
1013127
STRIP
- hold
1шт.
17
1032059
LOCK NUT
NUT - K-Lock: 18-8 SS .19 NC
4шт.
18
1033271
BOLT
- hex: .38 x 1.00 NC SS
2шт.
19
1033267
WASHER, LOCK
WASHER - lock: .38 SS
2шт.
20
1033266
WASHER
- flat: .38 SS
2шт.
21
1027931
SEAL
- extruded "P"
1шт.
22
1032033
ROD
ASSY - flow control rod
1шт.
23
1032190
JAM NUT
- jam: .50 NC SS
1шт.
24
1032089
CONTROL
ASSY - flow control plate
1шт.
25
1032032
SET OF PARTS
ASSY - metering door front
1шт.
26
1030046
DOOR
WLDMT - front door
1шт.
27
1013346
PINION
- rework
1шт.
28
1030001
LATCH ASSY.
LOCK - pointer
1шт.
29
425-144
JAM NUT,Jam, 1/4"-20, G5
- jam: .25 NC GR2 ZP
1шт.
30
1013092
BOLT
- special
1шт.
31
1021512
PIN
- roll: .25 x 1.38 ZP
1шт.
32
86636814
LUBE NIPPLE,1/4"-28 x .52" lg
ZERK - grease: .25 UNF STR
2шт.
33
1013283
DOOR ASSY.
ASSY - door: cleanout
1шт.
34
1013176
COVER
- rubber: cleanout door
1шт.
35
1013177
SUPPORT
- narrow
1шт.
36
1013177
SUPPORT
- narrow
1шт.
37
1013284
ANGLE
WLDMT - angle latch
1шт.
38
1033270
BOLT
BOLT - hex: .25 x .75 NC SS
16шт.
39
1033269
LOCK NUT
NUT - nylock: .25 NC SS
16шт.
41
1030865
POINT
BAR - pointer
1шт.
42
1030866
ANCHOR
WLDMT - flipper mount
1шт.
43
1030867
CLEVIS PIN
PIN - clevis: .50 x 1.25 ZP
1шт.
44
1011778
PIN, SPLIT (COTTER)
PIN - cotter: .13 x 1.00 NP
1шт.
45
1032094
LOCK NUT
NUT - K-Lock: #6 NC SS
4шт.
46
1032087
PLATE
WLDMT - flow control plate
1шт.
47
1027932
LARGE PLATE
PLATE - flow control
1шт.
48
1027884
SEAL
- rubber outer
1шт.
50
1029248
U-BOLT
TOGGLE ASSEMBLY
2шт.
51
1015173
BOLT
- hex: .31 x .75, NC, SS
1шт.
1013286
TOGGLE
used with part number 1029248, U BOLT
2шт.
52
1023719
NUT
- jam: .31, NC, SS
1шт.
Выбрано товаров: 52
