Запчасти Case IH ADX2230 (A.50.A[45]) - CONNECTOR SERVICE KIT A - Distribution Systems

0

13345V2

KIT

electrical connector

1шт.

1

425264A1

ELEC CONNECTOR,14 Pin

metal 14c receptacle

2шт.

2

425290A1

PLUG

connector, elec metal 14c

2шт.

3

225227C1

ELEC CONNECTOR,Female, 9 Pin

Plastic 9c Plug

2шт.

4

245329C1

CONNECTOR, ELEC

CONNECTOR elec metal 23c plug

2шт.

5

225224C1

ELEC CONNECTOR,Female, 5 Pin

plastic 5c plug

2шт.

6

795231

TERMINAL CONNECTOR,Female, 16 SAE

plastic 3c plug

2шт.

7

225222C1

ELEC CONNECTOR,Male, 5 Pin

plastic 5c receptacle fl

2шт.

8

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

16-18awg

20шт.

9

225348C1

ELEC. TERMINAL PIN,Male, 0.75 - 2.00 mm2

pin 16-18awg

20шт.

10

225404C1

POWER SOCKET,Nickel, 1.0 - 2.0mm

socket 14-16awg

20шт.

11

225406C1

ELEC. TERMINAL PIN,Male, 1 - 2 mm2

pin 14-16awg

20шт.

12

84068583

PLUG,12 - 16 Ga, White

connector cavity white plastic

10шт.

13

225226C1

CONNECTOR, ELEC

CONNECTOR elec plastic 9c receptacle

2шт.

14

51200869

TOOL

extraction Deutsch size 16

5шт.

15

425266A1

TOOL

hand crimp - Deutsch

1шт.

20

245715C1

ELEC CONNECTOR,4 Pin

plastic 4c plug

5шт.

21

87692855

CONTACT HOUSING,Male, 2 Cavities

plastic 2c plug

5шт.

22

87644909

WIRE CONNECTOR,Female, 3 Pins

plastic 3c plug

5шт.

23

87692877

MULTIPOLE CONNECTOR,Male, 2 Cavities

plastic 2c receptacle

5шт.

24

245485C1

ELEC CONNECTOR,Male, 3 Pin

plastic 3c receptacle

5шт.

25

245716C1

ELEC CONNECTOR,Male, 4 Pin

plastic 4c receptacle

5шт.

26

872290R1

ELEC CONNECTOR,Male

Plastic 2c Receptacle

5шт.

27

225123C1

TERMINAL CONNECTOR,Tin, 0.8mm

socket 18-20awg

10шт.

28

225122C1

TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm

socket 14-16awg

10шт.

29

225119C1

TERMINAL

14-16awg

10шт.

30

225120C1

TERMINAL CONNECTOR,Tin, 0.8mm

18-20awg

10шт.

31

1120922C1

ELEC CONNECTOR,Male, 1 - 2 mm2

blade 14-16awg

10шт.

32

225124C1

SEAL,2 - 2.9 mm2

seal grn 2.8-2 omm

20шт.

33

225125C1

SEAL

Connector Grey 3.49 - 2.81 mm

10шт.

34

1964525C1

TOOL

extraction - Packard, weather pack

5шт.

35

425267A1

TOOL

hand crimp - Packard, weather pack

1шт.

40

425057A1

ELEC CONNECTOR,4 Pin

plastic 4c plug

2шт.

41

10565

ELEC CONNECTOR,4 Pin

plastic 4c receptacle

2шт.

42

700718605

TERMINAL

pin 20-24awg

10шт.

43

225109C1

POWER SOCKET,Gold, 0.8 - 1.0mm

socket 16-18awg

30шт.

44

1964524C1

TOOL KIT

Removal

2шт.

45

ZJI2

TOOL

hand crimp - amp type III+

1шт.

50

51200018

PLIERS

cutter/stripper

1шт.

Not sold separately

1шт.

51

425268A1

TOOL BOX

complete

1шт.

52

221731A1

ELEC CONNECTOR,Female, 24 Pin

plastic 24c plug

6шт.

53

225171C1

ELEC CONNECTOR,Female, 16 Pin

plastic 16c plug

6шт.

54

87675194

MULTIPOLE CONNECTOR,Female, 3 Pole

plastic 3c plug

1шт.

55

425260A1

CONTACT HOUSING

socket 20-24awg

1шт.

56

445518

TERMINAL CONNECTOR,Tin, 5.00 - 8.00mm

socket 8-10awg

1шт.

57

425265A1

CONTACT HOUSING

socket 14-18awg

1шт.

58

425097A1

HANDBOOK

reference card, connector service kit

1шт.
