Запчасти Case IH ADX2230 (A.50.A[32]) - FLOW PARTS A - Distribution Systems

Схема запчастей Case IH ADX2230 - (A.50.A[32]) - FLOW PARTS A - Distribution Systems
10
12
8
3
9
19
14
15
10
16
11
11
18
13
9
4
11
6
2
17
14
5
7
1

Артикул

Название

Примечание

Количество

1

87419314

HARNESS

extension 4 m x 2c dtm

1шт.

1

87419315

HARNESS

extension 6 m x 2c dtm

1шт.

1

84213846

WIRE HARNESS

extension 9 m x 2c

1шт.

1

87419316

HARNESS

extension 13m 2 cond twist dtm

1шт.

2

87419317

HARNESS

seedflow interconnect 4.9 m

1шт.

2

87506449

HARNESS

seedflow interconnect 7.5 m

1шт.

3

87458502

SENSOR

particle flow optical shield, Start Year: 10-DEC-04

1шт.

4

87407453

DUST CAP

2c Deutsch receptacle

1шт.

5

87419318

TERMINAL CONNECTOR

terminator receptacle, 120 ohm - dtm 4

1шт.

6

87419319

PLUG

terminator, 120 ohm - dtm 4

1шт.

7

425269A1

DUST CAP

30 conductor

1шт.

8

470-11016

SCREW,Pan HD, #10 - 24 x 1"

1шт.

9

222136A1

ELEC CONNECTOR,Male, 2 Pin

plastic 2c receptacle

2шт.

10

222848A1

ELEC CONNECTOR

lock 2c receptacle

2шт.

11

223950A1

ELEC. TERMINAL PIN,Nickel, 0.8 - 1.0mm

18-20awg copper nickel plated

8шт.

12

222135A1

CONNECTOR, ELEC

CONNECTOR plastic 2c plug

1шт.

13

222846A1

STOP LOCK

2c plug connector

1шт.

14

223952A1

ELEC. TERMINAL PIN,Nickel, 0.8 - 1.0mm

socket 18-20awg

6шт.

15

277904A1

ELEC CONNECTOR,Female, 4 Pin

plastic 4c plug

1шт.

16

279794A1

STOP LOCK,Locking, Orange

4c plug connector

1шт.

17

277905A1

ELEC CONNECTOR,Male, 4 Pin

plastic 4c receptacle

1шт.

18

279795A1

STOP LOCK

4c receptacle connector

1шт.

19

225055C1

PLUG

connector 20awg

2шт.

100

87057798

INSTRUCTION

optical flow monitor

1шт.

Выбрано товаров: 24
