Запчасти Case IH ADX2230 (A.12.A[04]) - TBH HYD LINES ACROSS SDX30 (BSN CBJ0004433) A - Distribution Systems

1

51200106

HYDRAULIC HOSE,0.75" ID x 96.00", SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2

3/4" x 96" fl

1шт.

Fan Pressure

1шт.

2

51200106

HYDRAULIC HOSE,0.75" ID x 96.00", SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2

3/4" x 96" fl

1шт.

Fan Return

1шт.

3

51200109

HYDRAULIC HOSE,0.50" ID x 96.00", SAE 100R2AT, SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2

1/2" x 96" fl

1шт.

Case Drain

1шт.

4

1026677

STUD

3/8" x 3 1/4" nc gr d zp

1шт.

5

1026712

CLAMP

5"

1шт.

6

1026713

CLAMP

backing

1шт.

7

1026714

ISOLATOR

neoprene 1/4" tk pln

1шт.

8

1013043

WASHER

3/8" SAE

1шт.

9

232-1446

NUT,3/8"-16, GC

1шт.

10

1026743

HYD TUBE,0.5" Diameter, 108" Length

assy 1/2" x 108"

1шт.

11

1026745

TUBE,0.75" Diameter, 108" Length

assy 3/4" x 108"

1шт.

12

113-250

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd

1шт.

13

280284

BOLT,Hex, 3/8" - 16 x 7", Gr 5

1шт.

14

312995A1

MOUNTING PARTS

hyd clamp

1шт.

15

1994568C1

COUPLING, QUICK, FEM

1/2" fpt

1шт.

16

86592083

DUST CAP

pioneer coupler - 1/2"

1шт.

17

6934

PLUG

dust, pioneer coupler - 3/4"

1шт.

18

6935

COUPLING, QUICK, FEM

3/4"

1шт.

20

86977779

HYD CONNECTOR,1-1/16" - 12 JIC x 3/4" - 14 NPT

1шт.

21

132341

HYD CONNECTOR,3/4" - 16 JIC x 1/2" - 14 NPT

1шт.

22

351469A1

HOSE

1/2" x 48"

1шт.

23

350404A1

HOSE

3/4" x 48"

1шт.

24

1024393

HYD TUBE,19.1 mm OD, 3353 mm Length

hydraulic 3/4" x 132"

1шт.

25

1024392

HYD TUBE,12.7 mm Diameter, 3353 mm Length

hydraulic 1/2" x 132

1шт.
