12
0C
ORDER COMPONENTS
Lever, Twine Finger
1шт.
849384
1шт.
13
0C
ORDER COMPONENTS
Twine Finger
2шт.
9604536
1шт.
14
29579
SPRING
1шт.
16
710230
RIVET,Button, 9.53mm OD x 25.4mm L
2шт.
19
88275
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5
1шт.
21
87670
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
2шт.
25
280327
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd
4шт.
29
322358
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
4шт.
34
27697
WASHER,16.66mm ID x 27mm OD x 1.52mm Thk
2шт.
39
9635082
NUT,5/16" - 18, Gr 5
8шт.
42
9636698
NUT,1/2"-13, GB
2шт.
46
80755
COTTER PIN,1/8" OD x 1" L
2шт.
47
216698
COTTER PIN,0.125" OD x 1.75" L
2шт.
