Запчасти Case IH 5420 (9-44) - KNOTTER (09) - CHASSIS

1

1337771C1

FRAME

- knotter

2шт.

2

321204

LUBE NIPPLE,M6 x 1.0 x 16mm OAL

NIPPLE, LUBE, M6 x 1, 16mm lg

10шт.

3

3103537R1

BOLT

BOLT - hex, knotter

2шт.

4

3103544R1

CLEANER

PLATE - cleaner

4шт.

5

905251R1

LUBE NIPPLE,90 Degree, M6 x 1

FITTING - 90 degree lube, 6 mm

4шт.

8

3103542R1

GEAR

SHAFT AND PINION ASSEMBLY - knotter

2шт.

9

7852163

BUSHING

SHIM - pinion (Replaces 934512R1)

4шт.

10

1980618C1

NUT

- hex special, 10 mm - 1.0

2шт.

11

933965R1

LOCK WASHER,M10

2шт.

12

3103541R1

GEAR

- knotter

2шт.

13

732741R1

PIN, ROLL

PIN - roll

6шт.

15

3103540R1

GEAR

- retainer, twine

2шт.

16

3103539R1

HOLDER

RETAINER - twine

2шт.

17

700707903

TWINE

RETAINER - twine (Replaces 1337782C1)

2шт.

18

3103546R1

BOLT

BOLT - hex, retainer

2шт.

BAIL HOOK IS 700707906--ref item #20.

1шт.

21

3103549R1

GEAR

- hook, bill

4шт.

22

30020R1

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

- hex, 10 mm - 1.50 x 25 mm

2шт.

23

3103547R1

SPRING

- knife

2шт.

24

30168R1

NUT,M10, Cl 10

- hex, 10 mm

4шт.

25

3103536R1

CLUTCH

CATCH - knotter

2шт.

28

3103538R1

SPRING

- catch

2шт.

29

619855R1

WASHER

- flat, 25/64 x 3/4 x 3/64 inch

2шт.

31

1337775C1

ARM

- stripper

2шт.

33

1337780C1

KNIFE

- knotter

2шт.

34

3103531R1

BOLT

BOLT - hex, 4 mm - 0.7 x 10 mm

4шт.

35

3103532R1

RING

ROLLER - arm

2шт.

36

934512R1

SHIM,M15 ID x 21 OD x 1 Thk

- roller

8шт.

37

3103533R1

RETAINER

RING - snap

2шт.

38

933965R1

LOCK WASHER,M10

2шт.

40

1337774C1

PIN

SHAFT - arm, stripper

2шт.

41

3103534R1

SPACER

SHIM - arm

4шт.

42

3103535R1

RETAINER

RING - snap

2шт.
