Запчасти Case IH 200 (38) - BALE TENSION SHOES

1

F95401

SHOE - tension

2шт.

BOLT - 3/8" x 1" rhd. sq. nk. (11-616) nut (25-106) L.W. (92-6)

4шт.

2

A28084

WASHER

(1-1/2" O.D. x 41/64" I.D. x 3/16" thick) Tension handle

2шт.

3

F95403

HANDLE - tension

2шт.

4

F60653

ARM - upper

1шт.

BOLT - 3/8" x 3/4" rhd. sq. nk. (11-612) nut (25-106) L.W. (92-6)

4шт.

5

F60654

ARM - lower

1шт.

BOLT - 3/8" x 3/4" rhd. sq. nk. (11-612) nut (25-106) L.W. (92-6)

2шт.

6

F95402

SPRING - tension

2шт.

7

F2529

PLUG - tension spring

1шт.

8

F60553

HOLDER - chain bale diverter

1шт.

BOLT - 3/8" x 3/4" rhd. sq. nk. (12-612) nut (25-106) L.W. (92-6) bale diverter

1шт.

9

F60560

CHAIN (27 links) Bale chute bale diverter

1шт.

BOLT - 5/16" x 3/4" rhd. sq. nk. (11-512) nut (25-105) L.W. (92-5) bale diverter

1шт.

SCREW - 3/8" x 1-1/4" N.C. rhd. (75-620) fl. wshr. (95-6) bale diverter

1шт.

NUT - 3/8" N.C. hex. (25-106) bale diverter

2шт.

10

F95406

DIVERTER bale diverter

1шт.

SCREW - 3/8" x 1" N.C. rhd. (75-616) jam nut (25-146) bale diverter

2шт.
