Запчасти Case IH 200 (34) - NEEDLES (CONTD)

30

F60590

PITMAN - needle

1шт.

NUT - 5/8" N.F. hex. jam (25-1510)

1шт.

PIN - 3/16" x 1" cotter (132-91)

1шт.

31

F60646

CLIP - safety pin trip arm spring

1шт.

BOLT - 3/8" x 3/4" rhd. sq. nk. (11-612) nut (25-106) L.W. (92-6)

1шт.

32

F60934

SPRING - trip arm

1шт.

33

F2526

NEEDLE

2шт.

34

F60868

ARM - trip, safety pin rod (Replaced by F60944 when stocks are exhausted)

1шт.

F60944

ARM - trip, safety pin rod (Replaces F60868 when stocks are exhausted)

1шт.

35

F60880

SPACER (41/64" O.D. x 5/16" long) For F60944 arm

1шт.

36

F60644

ROD - safety latch (Replaced by F61176 when stocks are exhausted)

1шт.

PIN - 1/8" x 1" cotter (132-48)

1шт.

NUT - 1/2" N.F. hex. (25-118)

1шт.

F61176

ROD - safety latch (Replaces F60644 when stocks are exhausted)

1шт.

PIN - 1/8" x 1" cotter (132-48)

1шт.

NUT - 1/2" N.F. hex. (25-118)

1шт.

37

F60643

LATCH - safety

1шт.

38

F60945

PIN - safety arm

1шт.

PIN - 1/4" x 1-1/2" cotter (132-150)

2шт.

39

213-6

ADJUSTABLE CLEVIS,1/2"-20 x 3"

CLEVIS - 1/2"

1шт.

40

F95383

GUARD - needle

1шт.

BOLT - 3/8" x 1-3/4" N.F. hex. (14-628) nut (25-116) L.W. (92-6)

4шт.

41

F95494M

JACK (Machinery item) jack attachment

1шт.

42

F95498

BASE - jack jack attachment

1шт.

PIN - 3/16" x 2-1/4" cotter (132-101) jack attachment

1шт.

43

F60838

SPLIT PIN

PIN - hair, cotter jack attachment

1шт.

44

F60842

BRACE - jack jack attachment

1шт.

BOLT - 3/8" x 1-1/4" N.C. hex. (13-620) nut (25-106) L.W. (92-6) jack attachment

3шт.

F95470M

COVER - canvas (Use F96171M when stocks are exhausted) baler cover attachment

1шт.

F96171M

COVER - canvas (Replaces F95470M when stocks are exhausted) baler cover attachment

1шт.
