Запчасти Case IH 200 (14) - GEARBOX, FLYWHEEL AND CRANK ARM

1

O1917CH

WASHER (2-1/4" O.D. x 13/32" I.D. #12 ga.)

1шт.

2

F60894

WASHER (2-1/4" O.D. x 1-13/16" I.D. #18 ga.)

2шт.

3

F95395

CAP

- plunger Pitman

1шт.

4

F60624

BUSHING

(1-15/16" O.D. x 2" long)

1шт.

FITTING - 1/8" str. Lincoln #5000 (219-1)

1шт.

5

F60625

PAD - plunger Pitman cap

1шт.

BOLT - 7/16" x 1-1/4" N.C. hex. (13-720) L.W. (92-7)

2шт.

6

F2530

ARM - crank

1шт.

BOLT - 3/8" x 3-1/4" N.F. hex. (14-652) nut (25-116) L.W. (92-6)

1шт.

BOLT - 5/8" x 4-1/2" N.F. hex. (14-1072) nut (25-1110) L.W. (92-10)

2шт.

7

F60660

SPROCKET (20T) Pickup and knotter drive

1шт.

BOLT - 3/8" x 1" N.C. hex. (13-616) L.W. (92-6)

3шт.

8

F2547

CAP - gear box, R.H. end

1шт.

BOLT - 1/2" x 1-1/4" N.C. hex. (13-820) L.W. (92-8)

6шт.

9

F60830

SEAL - oil

1шт.

10

F60811

SHIM (.006") For F2547 cap

1шт.

11

F60831

SHIM (.010") For F2547 cap

1шт.

12

A15434

CUP

- R.H. end

1шт.

13

A27024

ROLLER BEARING,3.25" ID x 1.3125"

CONE - R.H. end

1шт.

14

F2544

GEAR BOX

1шт.

BOLT - 3/4" x 1-1/4" N.C. hex. (13-1220) L.W. (92-12)

6шт.

15

F60833

SHIM (.006") For F2546 cap

1шт.

16

F60834

SHIM (.010") For F2546 cap

1шт.

17

F95523

CARRIER - ring gear

1шт.

18

F60866

BOLT - carrier

12шт.

25-138

SLOTTED NUT,1/2"-20, G5

NUT - 1/2" N.F. hex.

12шт.

193-12

LOCK WASHER,Ext Tooth, 0.52" ID x 0.89" OD, STL, PLN

WASHER, LOCK, Ext Tooth, 1/2"

12шт.

41-36

PLUG,Exp, 2 1/4"

- 2-1/4" expansion

2шт.

19

A7892

BEARING, CUP

CUP - L.H. end

1шт.

20

F2546

CAP - gear box, L.H. end

1шт.

PLUG - pipe, 3/4" (221-5)

2шт.

BOLT - 7/16" x 1" N.C. hex. (13-716) L.W. (92-7)

12шт.

21

F60826

ROLLER BEARING

CONE - L.H. end

1шт.

22

F95522

GEAR - set of matched ring gear and pinion

1шт.

F60866

BOLT

12шт.

25-138

SLOTTED NUT,1/2"-20, G5

NUT - 1/2" N.F. hex.

12шт.

193-12

LOCK WASHER,Ext Tooth, 0.52" ID x 0.89" OD, STL, PLN

WASHER, LOCK, Ext Tooth, 1/2"

12шт.

23

F60996

WASHER (1-3/4" O.D. x 21/32" I.D. x 1/4" thick)

1шт.

24

14-1020

BOLT,Hex, 5/8" - 18 x 1-1/4", Gr 5

Hex, 5/8"-18 x 1 1/4

1шт.

LOCKWASHER - 5/8" (92-10)

1шт.

25

F60824

ROLLER BEARING

CONE - rear, flywheel pinion shaft

1шт.

26

F60823

CUP ASSY.

CUP - rear, flywheel pinion shaft

1шт.

27

F60825

CUP - front, flywheel pinion shaft

1шт.

28

A20301

CUP

CONE - front, flywheel pinion shaft

1шт.

29

F60813

LOCK NUT

LOCKNUT

1шт.

30

F60829

OIL SEAL

1шт.

31

F60812

GASKET - for F2548 cap

1шт.

32

V20203

PLATE

WASHER (2-1/2" O.D. x 1-21/32" I.D. #10 ga.)

1шт.

33

F2548

CAP - gear box front

1шт.

BOLT - 3/8" x 1" N.C. hex. (13-616) L.W. (92-6)

6шт.

34

F95583

BOLT AND NUT

- shear (Pkg. of 25 F60683 bolts and 25 131-351 nuts)

1шт.

35

F95727

FLYWHEEL

1шт.

36

F60682

SLEEVE

- flywheel shear bolt

1шт.

37

F60681

BUSHING

(1-3/4" O.D. x 1-1/4" long - split)

2шт.

38

F3902

ARM

- flywheel shear bolt

1шт.
