Запчасти Case IH 133 (42) - NEEDLES AND NEEDLE PITMAN

1

FB1020

NEEDLE

2шт.

2

B11801

SHIM - needle

1шт.

3

O1509B

WASHER - needle

1шт.

4

B15461

YOKE - needle

1шт.

5

B11930

BAND - brake

2шт.

BOLT - 3/8" x 2" N.C. hex. w/nut

2шт.

6

B11928

LINING

2шт.

RIVET - #4 tubular

8шт.

7

E156S

SPRING - adjusting, brake tension

2шт.

8

B11933

BOLT - adjusting, brake tension

2шт.

NUT - 3/8" N.C. hex. and L.W.

2шт.

WASHER - 3/8" flat

1шт.

9

O5476N

BRACKET - needle

2шт.

BOLT - 1/2" x 3-1/2" N.F. hex. w/nut and L.W.

4шт.

10

B11370

PIN - pivot, needle

2шт.

FITTING - 1/4" 28 thrd. str. Lincoln #5010

2шт.

PIN - 3/16" x 1-1/4" cotter

2шт.

BOLT - 3/8" x 1-1/4" N.F. hex. w/nut and L.W.

4шт.

11

O4380N

CLEVIS

- knotter Pitman

1шт.

12

141-6

CLEVIS PIN,1/2" x 1.360"

PIN - clevis, knotter Pitman

1шт.

PIN - 1/8" x 1" cotter

1шт.

13

B15450

PITMAN - needle

1шт.

NUT - 5/8" N.F. hex. jam

1шт.

PIN - 3/16" x 1" cotter

1шт.

14

B1036

ARM - needle Pitman

1шт.

BOLT - 3/8" x 2-1/2" N.F. hex. w/nut and L.W.

1шт.

15

126-129

WOODRUFF KEY,#C, 5/16" x 1 1/8", HT

Needle Pitman arm #C, 5/16" x 1 1/8", HT

1шт.

16

B15478

BRACE - upper, needle pivot angle

1шт.

NUT - 1/2" N.C. hex.

2шт.

17

T19471

PLOW BOLT

BOLT - (3/8" x 1-1/4" #3 plow w/nut) For ref. 19 angle

2шт.

LOCKWASHER - 3/8"

2шт.

18

B11491

BEARING - top, knotter shaft

1шт.

B11413

BUSHING

1шт.

19

B11404

ANGLE - upper, knotter support

1шт.

BOLT - 3/8" x 1" carr. w/nut and L.W.

2шт.

BOLT - 3/8" x 1" N.F. hex. w/nut and L.W.

4шт.

WASHER - 3/8" flat

2шт.

20

T19468

BOLT - (3/8" x 1" #3 plow w/hex. nut) For ref. 21 angle

1шт.

LOCKWASHER - 3/8"

1шт.

21

B11405

ANGLE - bottom, knotter support

1шт.

BOLT - 3/8" x 1" N.F. hex. w/nut and L.W.

2шт.

WASHER - 5/16" flat

1шт.

22

B15458

BRACKET - spring (Early production) See ref. 25

1шт.

23

B15037

ROD - Pitman (Early production)

1шт.

NUT - 3/8" N.F. hex.

2шт.

PIN - 3/8" x 1" cotter

1шт.

WASHER - 5/16" plain

1шт.

24

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, , For ref. 23 clevis (Early production) 3/8" x 1.060"

1шт.

PIN - 3/32" x 3/4" cotter

1шт.

25

O2532AB

CLIP - for ref. 29 spring (Later production)

1шт.

BOLT - 3/8" x 3/4" N.F. hex. w/nut and L.W.

1шт.

26

B15453

BASE - pivot pin (Early production)

1шт.

PIN - 1/8" x 1-1/4" cotter

1шт.

27

B15747

BASE - pivot pin (Later production)

1шт.

BOLT - 3/8" x 1" N.F. hex. w/nut and L.W.

2шт.

WASHER - 3/8" flat

2шт.

BOLT - 3/8" x 1-1/4" N.C. hex. w/jam nut

1шт.

28

327EB

SPRING

- Pitman arm latch (Early production)

1шт.

29

VT2155

X

SPRING - Pitman arm latch (Later production)

1шт.

30

B15456

LATCH - Pitman arm (Early production)

1шт.

31

B15749

LATCH - Pitman arm (Later production)

1шт.

FITTING - 1/4" 28 thrd. str. Lincoln #5010

2шт.

PIN - 1/8" x 1-1/4" cotter

1шт.

32

O578B

X

WASHER - 3 for ref. 26 base and 3 for ref. 13 Pitman (Early production)

6шт.

33

O774AB

X

WASHER - for ref. 13 Pitman (Later production)

3шт.

O774AB

X

WASHER - under ref. 31 latch (Later production)

2шт.

O774AB

X

WASHER - top of ref. 31 latch (Later production)

2шт.
