Запчасти Case IH 133 (28) - BALE CHAMBER DOGS, UPPER AND LOWER

1

B11212

HAY DOG

4шт.

2

141-6

CLEVIS PIN,1/2" x 1.360"

PIN - pivot, lower

2шт.

PIN - 1/8" x 1" cotter

2шт.

3

O1836FH

BOLT - shoulder, pivot - upper

2шт.

NUT - 7/16" N.F. hex. w/L.W.

2шт.

4

B15037

ROD - retainer

4шт.

NUT - 3/8" N.F. hex. w/fl. wshr.

4шт.

PIN - 1/8" x 1" cotter

4шт.

5

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, , Upper and lower 3/8" x 1.060"

4шт.

PIN - 3/32" x 3/4" cotter

4шт.

6

O5517N

SPRING - retainer

4шт.
