Запчасти Case IH 130 (25) - NEEDLES AND NEEDLE PITMAN

Схема запчастей Case IH 130 - (25) - NEEDLES AND NEEDLE PITMAN

Артикул

Название

Примечание

Количество

NLS

NO LONGER SERVICED

NEEDLE

2шт.

B1036

ARM - needle Pitman

1шт.

1/2" x 2" #2 plow bolt w/hex. nut and lockwasher

1шт.

B11370

PIN - pivot, needle

2шт.

1/4" 28 thrd. Lincoln fitting #5010

2шт.

3/16" x 1-1/4" cotter pin

2шт.

B11404

ANGLE - knotter support, top

1шт.

3/8" x 1" N.F. hex. hd. cap screw w/hex. nut and lockwasher

3шт.

3/8" x 1-1/2" N.F. hex. hd. cap screw w/hex. nut and lockwasher

2шт.

B11405

ANGLE - knotter support, bottom

1шт.

3/8" x 1-1/4" N.F. hex. hd. cap screw w/hex. nut and lockwasher

2шт.

B11462

BOLT - brake tension adjusting (Prior to serial #633738) See B11933

2шт.

3/8" N.F. hex. nut

2шт.

B11464

BAND - brake, w/lining (Prior to serial #633738) See B11930

2шт.

3/8" x 1-1/4" N.C. hex. bolt of nut

1шт.

B11466

LINING - brake (Prior to serial #633738) See B11928

2шт.

#8 - 5/8" ctsk. hd. brass tubular rivet

6шт.

B11621

GUARD - Pitman

2шт.

1/2" x 2" #3 plow bolt w/hex. nut and lockwasher

2шт.

B11637

YOKE - needle

1шт.

B11641

PITMAN - needle

1шт.

5/8" N.F. hex. jam nut

1шт.

3/16" x 1-1/2" cotter pin

1шт.

B11801

SHIM - needles (As required)

1шт.

B11928

LINING - brake (Serial #633738 and after) See B11466

2шт.

#4 - 5 tubular rivet

4шт.

B11930

BAND - brake w/lining (Serial #633738 and after) See B11464

2шт.

3/8" x 2" N.C. hex. bolt of nut

2шт.

B11933

BOLT - brake tension adjusting (Serial #633738 and after) See B11462

2шт.

B11945

CLIP - spring, needle Pitman

1шт.

1/4" x 3/4" bolt w/nut and lockwasher

1шт.

O2499AB1

X

PIN - clevis, knotter Pitman

1шт.

1/8" x 1" cotter pin

2шт.

O8651AB1

KEY - B1036 shaft arm

1шт.

O578B

X

WASHER - (1-1/4" O.D. x 21/32" I.D. #16 ga.) needle Pitman top of B1036 arm

1шт.

O2310CK

SPRING - needle Pitman

1шт.

1/4" x 2-3/4" cotter pin

1шт.

E156S

SPRING - brake tension adjusting

2шт.

O5850HT

SPACER - brake (Prior to serial #633738)

1шт.

O4380N

CLEVIS

- knotter Pitman

1шт.

O5476N

BRACKET - needle

2шт.

1/2" x 3-1/2" N.F. hex. hd. cap screw w/hex. nut and lockwasher

4шт.

1/2" plain washer

8шт.

Z1597

X

BOLT - (3/8" x 1-1/4" #3 plow w/hex. nut) for B11405 angle

2шт.

3/8" lockwasher

2шт.

Z1627

BOLT - (3/8" x 1" #3 plow w/hex. nut) for B11404 angle

2шт.

3/8" lockwasher

2шт.

Выбрано товаров: 47
