Запчасти Case IH LBX432S (06.54[01]) - CABLE HARNESS : 84448288 - C479 (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH LBX432S - (06.54[01]) - CABLE HARNESS : 84448288 - C479 (06) - ELECTRICAL SYSTEMS
x115
x107
x104
x203
x205
x117
x003
x103
home
x105
x202
x108
x102
x106
x200

Артикул

Название

Примечание

Количество

x003

84074252

TERMINAL CONNECTOR,Male

X3

1шт.

86500035

ELEC. TERMINAL PIN,Male, 0.75 - 2mm

1шт.

84068583

PLUG,12 - 16 Ga, White

1шт.

900552

ELEC. TERMINAL PIN,Male, 1 - 2 mm2

1шт.

x102

84074631

CONTACT HOUSING,Female, 2 Pole

X102

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x103

84074631

CONTACT HOUSING,Female, 2 Pole

X103

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x104

84074631

CONTACT HOUSING,Female, 2 Pole

X104

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x105

84074631

CONTACT HOUSING,Female, 2 Pole

X105

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x106

84074631

CONTACT HOUSING,Female, 2 Pole

X106

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x107

84074631

CONTACT HOUSING,Female, 2 Pole

X107

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x108

84074631

CONTACT HOUSING,Female, 2 Pole

X108

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x115

84074631

CONTACT HOUSING,Female, 2 Pole

X115

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x117

84074631

CONTACT HOUSING,Female, 2 Pole

X117

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

x200

84074643

CONTACT HOUSING,Female, 6 Pole

X200

1шт.

84074641

WEDGE

1шт.

900569

TERMINAL

1шт.

x202

86500035

ELEC. TERMINAL PIN,Male, 0.75 - 2mm

X202

1шт.

84074630

CONTACT HOUSING,Male, 2 Pole

1шт.

86500166

ELEC CONNECTOR

1шт.

x203

441166

TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm

X203

1шт.

446133

ELEC CONNECTOR,Female, 2 Pin

1шт.

x205

441166

TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm

X205

1шт.

446133

ELEC CONNECTOR,Female, 2 Pin

1шт.

Выбрано товаров: 41
