Запчасти Case IH LB434R XL (90.119.025) - PROTECTIONS FLYWHEEL (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84284827

COVER

1шт.

2

87716226

EMBLEM

1шт.

3

190132

RUBBER WASHER

2шт.

4

84429041

LOCKING RING

2шт.

5

12647004

WASHER,8.15mm ID x 25mm OD x 2.5mm Thk

38шт.

6

43133

BOLT,Hex, M8 x 1.25 x 80mm, Cl 8.8

2шт.

7

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

36шт.

8

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

12шт.

9

84599753

PLATE

1шт.

10

412650

BELLEVILLE WASHER,M8 Bolt Size x 22mm OD x 1.4mm Thk

2шт.

11

47485673

CANVAS

1шт.

12

84280063

HALF-HINGE

23шт.

13

84397010

SHIELD

1шт.

14

84397009

SHIELD

1шт.

15

47995952

PANEL

1шт.

16

47995957

PANEL

1шт.

17

47407187

RIVET

7шт.

18

86624182

WASHER,6.6mm ID x 18mm OD x 1.6mm Thk

7шт.

19

47734414

HANDRAIL

1шт.

20

47994927

BRACKET

, Serial Range: -C174

1шт.

20

48081180

, Start Serial: D175

BRACKET

1шт.

21

16045721

SCREW,Hex, M8 x 125mm, Cl 8.8

, Serial Range: -C174

4шт.

21

381522

BOLT,Hex, M8 x 1.25 x 130mm, Cl 8.8

, Start Serial: D175

4шт.

22

120061

BOLT,Hex, M8 x 60mm L, Cl 8.8

2шт.

23

308761

CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8

, Serial Range: -C174

4шт.

23

86633356

CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8

, Start Serial: D175

4шт.

24

9706690

NUT,M8 x 1.25, Cl 8

8шт.

25

84563638

BRACKET

2шт.

26

47361726

PLATE

1шт.

27

158188

PLUG,19mm Hole, 28.6mm OD

4шт.

28

86619060

CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8

4шт.

29

47994958

BRACKET

, Serial Range: -C174

1шт.

29

48081183

, Start Serial: D175

BRACKET

1шт.

30

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

16шт.

31

12647004

WASHER,8.15mm ID x 25mm OD x 2.5mm Thk

, Serial Range: -C174

4шт.

31

86625253

WASHER,11mm ID x 24mm OD x 2mm Thk

, Start Serial: D175

4шт.

32

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

, Serial Range: -C174

4шт.

32

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

, Start Serial: D175

4шт.

33

9706690

NUT,M8 x 1.25, Cl 8

, Serial Range: -C174

4шт.

33

100016

NUT,M10 x 1.5, Cl 8

, Start Serial: D175

4шт.
