Запчасти Case IH LB433S (06.516[01]) - CABLE HARNESS: 84459691 - NOT FOR NA (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH LB433S - (06.516[01]) - CABLE HARNESS: 84459691 - NOT FOR NA (06) - ELECTRICAL SYSTEMS
x503
2
x502
3
x123
4
x207
home
1

Артикул

Название

Примечание

Количество

1

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

1шт.

2

441166

TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm

1шт.

441159

CONTACT HOUSING,Female, 1 Pole

1шт.

3

441166

TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm

1шт.

441159

CONTACT HOUSING,Female, 1 Pole

1шт.

430026

TERMINAL CONNECTOR,1 - 2.5mm

1шт.

4

441166

TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm

1шт.

441159

CONTACT HOUSING,Female, 1 Pole

1шт.

430026

TERMINAL CONNECTOR,1 - 2.5mm

1шт.

x123

426199

TERMINAL CONNECTOR,Female, 1 - 2.5 mm2

X123

1шт.

398225

MULTIPOLE CONNECTOR,7 Pin

1шт.

x207

86500035

ELEC. TERMINAL PIN,Male, 0.75 - 2mm

X207

1шт.

84074636

WIRE CONNECTOR,Male

1шт.

9861376

CONTACT HOUSING

1шт.

x502

86500035

ELEC. TERMINAL PIN,Male, 0.75 - 2mm

X502

1шт.

84074636

WIRE CONNECTOR,Male

1шт.

9861376

CONTACT HOUSING

1шт.

x503

335482

TERMINAL CONNECTOR,1.5 - 2.5 mm2

X503

1шт.

84068583

PLUG,12 - 16 Ga, White

1шт.

84074631

CONTACT HOUSING,Female, 2 Pole

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

84074630

CONTACT HOUSING,Male, 2 Pole

1шт.

86500166

ELEC CONNECTOR

1шт.

Выбрано товаров: 23
