(06.517[01]) - CABLE HARNESS: 84459692

Запчасти Case IH LB333R (06.517[01]) - CABLE HARNESS: 84459692 (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH LB333R - (06.517[01]) - CABLE HARNESS: 84459692 (06) - ELECTRICAL SYSTEMS
x121
x122
home
x502
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

x121

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

X121

1шт.

84074631

CONTACT HOUSING,Female, 2 Pole

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

x122

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

X122

1шт.

84074631

CONTACT HOUSING,Female, 2 Pole

1шт.

84074638

LOCKING TAB,Locking Wedge, Green

1шт.

x502

86500036

TERMINAL,Female, Nickel, 0.75 - 2mm

X502

1шт.

84074637

WIRE CONNECTOR,Female

1шт.

84074640

LOCKING TAB,Wedge Lock

1шт.
