1
84216309
FEED ROLLER
1шт.
FOR LB324R LB334R ONLY
1шт.
1
84216298
FEED ROLLER
1шт.
FOR LB424R LB434R ONLY
1шт.
2
36403
BEARING HOUSING
4шт.
3
9837842
BEARING,35mm ID x 72mm OD x 19mm W
2шт.
MAINTENANCE PART
1шт.
4
86633356
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
3шт.
5
140045
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
6шт.
6
100016
NUT,M10 x 1.5, Cl 8
6шт.
7
84488422
SPROCKET
1шт.
8
84429871
WASHER
4шт.
9
370004
SNAP RING,M35 x 1.5mm Thk, External
1шт.
10
170012
KEY,8mm W x 50mm OAL
1шт.
11
84338874
SPROCKET
1шт.
12
370011
CIRCLIP,M52 x 2mm Thk, Internal
1шт.
13
34439
BALL BEARING,25 mm ID x 52 mm OD x 15 mm
, Serial Range: -C047
1шт.
13
443898
BALL BEARING,25mm ID x 52mm OD x 15mm W
, Start Serial: D048
1шт.
14
419854
WASHER,26mm ID x 35mm OD x 1mm Thk
6шт.
15
370002
CIRCLIP,M25, External
1шт.
16
86633356
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
, Serial Range: -C035
3шт.
