Запчасти Case IH LB324P (55.100.030) - KNOTTER CLEANING FANS (55) - ELECTRICAL SYSTEMS

1

84273586

WIRE HARNESS

1шт.

2

84275427

FAN

2шт.

3

14496501

WASHER,8.4mm ID x 17mm OD x 1.6mm Thk

8шт.

4

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

, Serial Range: -C136

8шт.

4

43129

BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8

, Start Serial: D137

8шт.

5

9812123

BUSHING,8.5mm ID x 16mm OD x 7mm L

8шт.

6

87556072

NUT,Flng, 11.8mm OD x 19.8mm L

, Start Serial: D137

8шт.

7

84391774

SENSOR

, Start Serial: D162

1шт.

8

47414530

WIRE CONNECTOR

, Start Serial: D162

1шт.
