Запчасти Case IH 8590 (2-04) - FLYWHEEL BRAKE ASSEMBLY Driveline

1

326-1048

BOLT,Hex, 5/8" - 11 x 3", Gr 8

1шт.

2

700711198

LOCK NUT

5/8-11 HFTLN GR/G, special

1шт.

3

700710984

SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC

1/2-13 HFTLN GR/G

4шт.

4

231-5348

FLANGE NUT,Flg, 1/2"-13

1/2-13 HFTLN GR/G

4шт.

5

700113022

SUPPORT

- bearing

1шт.

6

700110467

BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm

BEARING ASSEMBLY (Includes Ref: 11)

1шт.

7

433-820

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 X 1-1/4 RHSNB

6шт.

8

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

5шт.

9

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

5шт.

10

700113039

SHAFT

ASSEMBLY

1шт.

11

51318

BEARING

- spherical

1шт.

12

495-21056

WASHER,1/2"

1/2 HARDENED PLAIN WASHER

4шт.

13

706176

SCREW

5/16-18 X 3/4 CRTHMS

2шт.

14

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT, Flg, USR, 5/16"-18

2шт.

15

432-1016

COTTER PIN,5/32" x 1"

5/32" x 1"

1шт.

16

700113058

BRAKE BAND

BRAKE ASSEMBLY (Includes Ref: 13 and 14)

1шт.

17

413-872

BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5

1/2-13 X 4-1/2 C

1шт.

18

700714586

FLANGE NUT

1/2-13 HFN GR8

2шт.

19

700112893

CHANNEL

- right

1шт.

20

6524003

SPACER

1шт.

21

766667

BOLT,1/2" - 13 x 10"

1/2-13 X 10 EYEBOLT

1шт.

22

700113052

STOP

1шт.

23

700113057

PIN

- trunnion

1шт.

24

231-1448

NUT,1/2"-13, GB

1/2-13 LHSN

2шт.

25

27342

GRIP

- handle

1шт.

26

432-1224

COTTER PIN,3/16" x 1-1/2"

3/16" x 1 1/2"

2шт.

27

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

28

496-11041

WASHER,13/32" x 13/16" x .065", HDN

3/8 HARDENED PLAIN WASHER

4шт.

29

232-5316

FLANGE NUT,Flg, 3/8"-16

3/8-16 HFTLN GR/G

2шт.

30

6489231

SPACER

2шт.

31

700113054

LEVER

WA - brake

1шт.

32

434-616

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5

3/8-16 X 1 RHSNB

2шт.

33

329-286

FLANGE NUT,Flg, 3/8"-16, G8

2шт.

34

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

C Hex, 5/16"-18 x 3/4", G5, Full Thd

1шт.

35

232-5315

FLANGE NUT,Flg, 5/16"-18

5/16-18 HFTLN GR/G

1шт.

36

439-5848

HEADED PIN,1/2" x 3", G5

1/2 X 3 CLEVIS PIN

1шт.
