Запчасти Case IH 8585 (2-12) - FLYWHEEL BRAKE ASSEMBLY Driveline

1

6489231

SPACER

2шт.

2

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

3

496-11041

WASHER,13/32" x 13/16" x .065", HDN

3/8 HARDENED PLAIN WASHER

2шт.

4

232-5316

FLANGE NUT,Flg, 3/8"-16

3/8-16 HFTLN GR/G

2шт.

5

231-1448

NUT,1/2"-13, GB

1/2-13 LHSN

2шт.

6

766667

BOLT,1/2" - 13 x 10"

1/2-13 X 10 EYE BOLT

1шт.

7

439-5848

HEADED PIN,1/2" x 3", G5

1/2 X 3 CLEVIS PIN

1шт.

8

495-21056

WASHER,1/2"

1/2 HARDENED PLAIN WASHER

12шт.

9

432-1016

COTTER PIN,5/32" x 1"

5/32" x 1"

1шт.

10

706176

SCREW

5/16 X 3/4 CRPHMS

2шт.

11

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT, Flg, USR, 5/16"-18

2шт.

12

700113058

BRAKE BAND

BRAKE ASSEMBLY (Includes items 10 and 11)

1шт.

13

6524003

SPACER

1шт.

14

413-872

BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5

1/2-13 X 4-1/2 C

1шт.

15

231-5348

FLANGE NUT,Flg, 1/2"-13

1/2-13 HFTLN GR/G

1шт.

16

700137607

CHANNEL

WA

1шт.

17

433-816

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5

1/2-13 X 1 RHSNB

2шт.

18

329-288

FLANGE NUT,Flg, 1/2"-13, G8

2шт.

19

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

C Hex, 5/16"-18 x 3/4", G5, Full Thd

1шт.

20

232-5315

FLANGE NUT,Flg, 5/16"-18

5/16-18 HFTLN GR/G

1шт.

21

700113057

PIN

- brake

1шт.

22

27342

GRIP

HANDLE GRIP

1шт.

23

700113054

LEVER

HANDLE WA

1шт.

24

432-1224

COTTER PIN,3/16" x 1-1/2"

3/16" x 1 1/2"

2шт.
