Запчасти Case IH 8585 (6-52) - HARNESS ASSEMBLY, FRONT VALVE (14) - BALE CHAMBER

1

700720097

MANIFOLD

VALVE - divider

1шт.

2

700706841

PLUG

- closure

2шт.

3

700706839

GASKET,10.31mm ID x 13.82mm OD x 0.84mm Thk

2шт.

4

700714008

HYD CONNECTOR

FITTING - quickline

8шт.

5

700720091

HYD CONNECTOR

CONNECTOR - swivel

1шт.

6

700720092

3 WAY CONNECTION

TEE

1шт.

7

219-36

LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF

1/8-27 X 90° ZERK

1шт.

8

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

2шт.

RE: the tube with the #8 in triangle above it (on left side of picture). This connects to 700706682 elbow fitting which can be found in the Lube Assembly (front) page 6-42.

1шт.

9

700720093

HARNESS

- lube, pickup

1шт.

10

700706681

LINE

- lube

1шт.
