Запчасти Case IH 57 (A-39[A]) - BALE LENGTH CONTROL

1

663584R94

ROD ASSY, trip, for service replacement of 663584R93 also order collar, 670669R1

1шт.

Used on 57 twine balers

1шт.

1

662279R94

MOUNTING ROD

ROD ASSY, trip, for service replacement of 662279R93 also order collar, 670669R1

1шт.

Used on 57 wire balers

1шт.

18265R1

LOCK PIN,3/8" x 1 1/4", Slotted

Pin, 3/8" x 1 1/4", Slotted

1шт.

2

670669R1

COLLAR

trip set, replaces 666748R2

1шт.

3

667782R1

SHEAVE

ROLLER, trip

2шт.

4

667781R1

ROLLER

SPACER, trip roller

1шт.

5

667778R1

BUSHING

trip sheave support, 501G thru 1400H

2шт.

6

SUPPORT, trip sheave, (not serviced separately) order trip sheave support assy

1шт.

7

667450R92

SUPPORT ASSY, trip sheave, 501G thru 1400h

1шт.

BOLT, 3/8-16 x 1 short sq-nk crg

2шт.

BOLT, 5/8-11 x 1-1/2 hex-hd mach

1шт.

NUT, 3/8-16 hex.

2шт.

WASHER, 3/8 med lock

2шт.

WASHER, 5/8 med lock

1шт.

Q1505

WASHER

13/32 x 1 x 16 ga

2шт.

8

667452R91

WHEEL ASSY, meter, 501G thru 1400H

1шт.

551659R1

WASHER

29/32 x 1-1/2 x 22 ga

2шт.

9

663349R1

SHAFT, trip arm

1шт.

Used on 57 wire balers

1шт.

Q3501

WASHER

25/32 x 1-1/4 x 16 ga (or as required)

2шт.

551658R1

WASHER

25/32 x 1-1/4 x 22 ga (or as required)

1шт.

10

668048R1

CLIP

trip spring

1шт.

NUT, 3/8-16 hex.

1шт.

SCREW, 3/8-16 x 1-1/2 hex-hd cap

1шт.

WASHER, 3/8 med lock

1шт.

Q1597

WASHER

13/32 x 3/4 x 16 ga

1шт.

11

6646

SPRING

trip rod

1шт.

12

663547R1

AXLE PIN

STUD, trip arm

1шт.

Used on 57 twine balers

1шт.

PIN, 1/8 x 1 cot.

1шт.

Q3501

WASHER

25/32 x 1-1/4 x 16 ga (or as required)

2шт.

551658R1

WASHER

25/32 x 1-1/4 x 22 ga (or as required)

1шт.

13

70733H

SPRING

trip arm

1шт.

PIN, 5/32 x 1 cot.

1шт.

14

663163R21

ARM

W/ROLLER, trip

1шт.

Used on 57 wire balers

1шт.

15

662020R1

STUD

trip arm roller

1шт.

PIN, 3/32 x 3/4 cot.

1шт.

PIN, 5/16 x 3 cd-pltd cot.

1шт.

Used on 57 wire balers

1шт.

17053R1

LOCK PIN,Sl Spring, 1/4" x 1 3/8"

PIN, 1/4" x 1 3/8", Slotted

1шт.

28035K

WASHER

13/32 x 1 x 22 ga

1шт.

16

662019R1

ROLLER,28.57mm OD x 12.7mm L

trip arm

1шт.

17

ARM, trip, (not serviced separately) order trip arm w/roller

1шт.

18

662018R11

LEVER

ARM W/ROLLER, trip

1шт.

Used on 57 twine balers

1шт.

19

ARM, trip, (not serviced separately) order trip arm w/roller

1шт.

20

668999R1

BUSHING

meter wheel flanged, 1401H up

2шт.

21

669000R1

TUBE, meter wheel shaft, 1401H up

1шт.

BOLT, 5/8-11 x 5-1/2 hex-hd mach

1шт.

NUT, 5/8-11 hex.

1шт.

WASHER, 5/8 med lock

1шт.

22

669001R1

WHEEL, bale length control, 1401H up

1шт.

23

670665R1

BRACKET, meter wheel shaft bearing, replaces 668998R1, if 668998R1 is required order 670665R1, 2670670R1, 215023R1, 2102635 and 2103321

1шт.

24

670670R1

SPACER, meter wheel bracket

2шт.

18684R1

BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2

3/8 x 1-1/4 sq-nk crg

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

619856R1

WASHER

13/32 x 1 x 16 ga C-Z

2шт.
