Запчасти Case IH 46 (30) - NEEDLE AND NEEDLE PITMAN, FOR NO. 46-T BALER

1

662152R2

GUSSET, axle, left

1шт.

17427R1

BOLT, mach., hex-hd., 7/16-14NC x 1"

2шт.

NLS

NO LONGER SERVICED

hex., 7/16-14NC

2шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

2шт.

2

662129R2

GUARD, needle, left

1шт.

14995R1

BOLT

carriage, 3/8-16NC x 3/4"

3шт.

102635

NUT,3/8"-16, G5

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

3

662282R1

PITMAN

needle

1шт.

425-1110

NUT,5/8"-18, G5

1шт.

103385

COTTER PIN,1/8" x 1"

PIN, SPLIT (COTTER), 1/8" x 1"

1шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

1шт.

350515R1

WASHER

plain, 21/32" ID x 1" OD no. 16 ga.

1шт.

Q3501

WASHER

plain, 25/32" ID x 1-1/4" OD x no. 16 ga.

1шт.

4

127786

ADJUSTABLE CLEVIS,5/16"-18 x 4 15/16"

CLEVIS, adjusting, needle Pitman

1шт.

108630

COTTER PIN,1/8" x 7/8"

PIN, SPLIT, (COTTER), 1/8" x 7/8"

1шт.

98795H

CLEVIS PIN,5/8" x 1.781"

PIN, rod end (5/8 x 1-27/32")

1шт.

5

219-40

LUBE NIPPLE,65 Degree Elbow, 1/8" - 27 NPTF

lubrication, 65 degree elbow, 1/8"

2шт.

6

662029R1

PIVOT

BEARING, needle pivot

2шт.

17496R1

BOLT,Hex, 3/8" - 16 x 1 3/4"

mach., hex-hd., 3/8-16NC x 1-3/4

2шт.

102635

NUT,3/8"-16, G5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

7

495206R1

WEDGE

PIVOT AND WEDGE, needle

2шт.

14996R1

BOLT, carriage, 7/16-14NC x 3/4"

4шт.

NLS

NO LONGER SERVICED

hex., 7/16-14/NC

4шт.

432-1232

COTTER PIN,3/16" OD x 2" L

Pin, Split (Cotter), 3/16" x 1 3/4"

2шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

4шт.

Q121

WASHER

plain, 1-9/32" ID x 2" OD x no. 16 ga.

4шт.

8

662168R91

PIPE

needle tie (Welded assembly)

1шт.

9

662034R2

NO LONGER SERVICED

NEEDLE

2шт.

179887

CABLE

4шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

4шт.

PO10535

WASHER

plain, 17/32" ID x 1-1/4" OD x no. 11 ga.

4шт.

10

11833PB

GUIDE

twine

4шт.

11

11792P

HOLDER

twine guide

1шт.

17519R1

BOLT,Hex, 1/4" - 20 x 2", Gr 2

mach., hex-hd., 1/4-20NC x 2"

2шт.

109084

NUT,1/4"-20, G5

2шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

12

662130R2

GUARD, needle, right

1шт.

14995R1

BOLT

carriage, 3/8-16NC x 3/4"

3шт.

102635

NUT,3/8"-16, G5

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

13

662211R2

GUSSET, axle, center

1шт.

15551R1

BOLT,3/8"-16 x 1", G2, Full Thd

plow, 3/8-16NC x 1"

5шт.

102635

NUT,3/8"-16, G5

5шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

5шт.

14

662155R1

SUPPORT, twine guide bracket

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, carriage, 3/8-16NC x 1"

2шт.

102635

NUT,3/8"-16, G5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

15

496158R2

BRACKET

twine guide

3шт.

14994R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

3шт.

9635082

NUT,5/16" - 18, Gr 5

hex., 5/16-18NC

3шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

3шт.
