Артикул
Название
Примечание
Количество
1
674089R1
GUARD
needle
1шт.
17351R1
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
BOLT, 3/8 x 1 znd sq-nk crg
2шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
18794R1
BOLT,Hex, 7/16" - 14 x 1", Gr 2
7/16 x 1 znd hex-hd mach
2шт.
NLS
NO LONGER SERVICED
NUT, 7/16-14 znd hex.
2шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
2шт.
607891R1
WASHER
15/32 x 1 x 16 ga C-Z
2шт.
2
201095C2
PIPE
ASSY, needle tie
1шт.
608701R1
WASHER
21/32 x 1-1/4 x 16 ga C-Z
6шт.
18481R1
COTTER PIN,3/16" x 1"
PIN, SPLIT (COTTER), 3/16" x 1"
2шт.
3
80722
LUBE NIPPLE,3/16" x .55" lg, Drive
FITTING, 3/16 str drive lub
1шт.
4
674098R1
STRAP
needle pivot support LH
1шт.
18684R1
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
3/8 x 1-1/4 C-Z sq-nk crg
2шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
5
127786
ADJUSTABLE CLEVIS,5/16"-18 x 4 15/16"
CLEVIS, 5/8-18 x 4-15/16 HV rod end
1шт.
22754R1
CLEVIS PIN,5/8" x 1.844"
PIN, CLEVIS, , Rod end 5/8" x 1.844"
1шт.
6
NOT SERVICED SEPARATELY, order 201667C91
1шт.
7
SHOE, knotter shaft brake RH, not serviced separately, order 754778R91
1шт.
8
LINING, knotter shaft brake, not serviced separately, order 754777R91 or 754778R91
2шт.
9
SHOE, knotter shaft brake LH, not serviced separately, order 754777R91
1шт.
10
201670C1
DRAWBAR
CRANK, needle drive
1шт.
181620
SCREW,Hex, 5/16" - 24 x 2", Gr 5
5/16-24 znd hex-hd cap shear bolt
1шт.
120368
NUT,5/16"-24, G5
1шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
1шт.
11
181620
SCREW,Hex, 5/16" - 24 x 2", Gr 5
BOLT, shear 5/16-24 x 2 C-Z hex-hd cap screw
1шт.
12
662555R1
BUSHING,8.46mm ID x 15.98mm OD x 12.83mm L
shear bolt
1шт.
13
Q72
KEY,5/16" Sq x 1 7/8", Par
3/8 x 1-7/8 sq parallel
1шт.
14
202710C91
HUB
needle drive crank, includes 662555R1 bushing
1шт.
443057
GROOVED PIN,3/8" x 2 1/4", Type F
Pin, Grooved, 3/8" x 2 1/4", Type F
1шт.
15
662153R1
PLATE
knotter brake pressure
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
16
U13033
SPRING
knotter brake
2шт.
18770R1
BOLT,Hex, 5/16"-18 x 2 3/4", G2
5/16 x 2-3/4 C-Z hex-hd mach
2шт.
120376
NUT,5/16"-18, G5
4шт.
120393
BEARING WASHER,5/16", SAE
WASHER 11/32 x 11/16 x .065 C-Z
2шт.
17
200588C5
NEEDLE
twine
2шт.
179889
BOLT,Hex, 1/2" - 13 x 2", Gr 5
SCREW, 1/2-13 x 2 hex-hd cap
4шт.
120384
WASHER,1/2"
LOCK, 1/2"
4шт.
455150R1
WASHER
17/32 x 1-1/4 x 1/4
4шт.
18
670617R2
GUIDE
twine
4шт.
436732
SCREW,Slotted Pan Hd, #10-24 x 1/2"
10-24 x 1/2 C-Z slt-pan-hd mach
8шт.
120217
LOCK WASHER,#10
WASHER, LOCK, #10
8шт.
19
352133R1
PLATE
twin guide mounting
4шт.
20
674097R2
BRACKET
slack spring
1шт.
21
457094R1
SPRING
slack arm
2шт.
22
670621R1
RING
slack arm
2шт.
18778R1
SCREW,Hex, 3/8"-16 x 3/4", G2
BOLT, 3/8 x 3/4 C-Z hex-hd mach
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
469668R1
WASHER
13/32 x 3/4 x 16 ga C-Z
1шт.
21644R1
PIN,1/4" x 1"
Split (Cotter), 1/4" x 1"
2шт.
23
674096R1
STRAP
needle pivot support RH
1шт.
24
87415
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
NIPPLE, LUBE, 90°, 1/4" NPT x .75" lg, Drive
2шт.
25
203056C1
PIVOT
ASSY, needle tie pipe RH
1шт.
26
674099R1
WEDGE
hay
2шт.
15003R1
BOLT,Sq Nk, 7/16" x 7/8"
7/16 x 7/8 sq-nk crg
4шт.
664646R1
LOCK NUT,7/16"-14, GB
NUT, 7/16-14 hex lock
4шт.
27
203055C1
LARGE PIN
PIVOT ASSY, needle tie pipe LH
1шт.
28
754777R91
SHOE
ASSY, knotter shaft brake LH
1шт.
29
754778R91
SHOE
ASSY, knotter shaft brace RH
1шт.
413-432
SCREW, 1/4-20 x 2 znd hex-hd cap
1шт.
120375
NUT,Hex, 1/4" - 20, Gr 5
2шт.
30
201667C91
PITMAN
W/PIN, needle
1шт.
425-110
5/8-18 znd hex.
1шт.
21796R1
WASHER
21/32 x 1 x 16 ga C-Z
2шт.
137185
COTTER PIN,1/8" x 1"
PIN, SPLIT (COTTER), 1/8" x 1"
1шт.
31
NOT SERVICED SEPARATELY, order 201667C91
1шт.
Выбрано товаров: 72
