1
674100R2
SUPPORT
knotter shaft brg
1шт.
17351R1
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
BOLT, 3/8 x 1 C-Z sq-nk crg
2шт.
18684R1
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
3/8 x 1-1/4 znp sq-nk crg
2шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
469668R1
WASHER
13/32 x 3/4 x 16 ga znp
2шт.
2
200414C1
FILLER, breast plate LH, 430 Baler 50 in. thru 007960, 440 Baler 50 in. thru 002768
1шт.
2
202584C1
LARGE PLATE
FILLER, breast plate LH, 430T Balers 007961 and up, 440T Balers 002769 and up
1шт.
3
667779R31
PLATE
ASSY, breast
1шт.
4
22803R1
PIN,1/2" x 9 1/4"
1/2 x 9-1/4 C-Z std hd
1шт.
18481R1
COTTER PIN,3/16" x 1"
PIN, SPLIT (COTTER), 3/16" x 1"
1шт.
5
662007R2
RETAINER
hay
2шт.
6
668869R1
SPRING
hay retainer
2шт.
7
662009R3
ANCHOR
knotter
2шт.
19019R1
CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2
BOLT, 3/8 x 1 C-Z No. 3 plow
2шт.
18494R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8 x 1 C-Z hex-hd mach
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
138489
LOCK WASHER,Ext Tooth, 3/8"
WASHER, LOCK, Ext Tooth, 3/8"
2шт.
8
662146R1
BRACKET
hay retainer pivot upper
1шт.
18494R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8 x 1 C-Z hex-hd mach
1шт.
18495R1
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
3/8 x 1-1/4 C-Z hex-hd mach
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
9
200415C1
FILLER, breast plate RH, 430 Baler 50 in. thru 007960, 440 Baler 50 in. thru 002768
1шт.
9
202585C2
FILLER
breast plate RH, 430T Balers 007961 and up, 440T Balers 002769 and up
1шт.
17351R1
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
BOLT, 3/8 x 1 znp sq-nk crg
3шт.
120377
NUT,3/8" - 16, Gr 5
3шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
3шт.
469668R1
WASHER
13/32 x 3/4 x 16 ga znp
2шт.
10
667810R21
FRAME
W/BUSHINGS, knotter drive
1шт.
18619R1
BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 2
5/8 x 2-1/4 C-Z hex-hd mach
1шт.
280374
NUT,Hex, 5/8" - 11, Gr 5
5/8-11 C-Z hex
1шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
1шт.
11
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg
2шт.
12
667811R1
BUSHING
trip arm stud
2шт.
13
662112R1
SPRING
twine retainer
2шт.
216378
RIVET
1/4 x 7/16 znp csk-hd small solid
4шт.
18508R1
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
BOLT, 3/8 x 3/4 C-Z sq-nk crg
1шт.
19019R1
CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2
BOLT, 3/8 x 1 C-Z No. 3 plow
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
134489
HUB
WASHER, 3/8 C-Z ext-tooth lock
1шт.
19009R1
CARRIAGE BOLT,#3, 5/16" - 18 x 1 1/2", Gr 2
BOLT, 5/16 x 1-1/2 znd No. 3 plow
2шт.
19007R1
PLOW BOLT,#3, 5/16" - 18 x 1", Gr 2
BOLT, 5/16 x 1 plow
2шт.
120376
NUT,5/16"-18, G5
4шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
4шт.
14
204631C91
FINGER
W/RIVETS, base plate, replaces 495412R71 and 668975R12
2шт.
216380
RIVET
1/4 x 7/8 znp csk-hd small solid
4шт.
123821
RIVET
1/4 x 5/8 znp csk-hd small solid
4шт.
15
495929R2
WEDGE
hay retainer narrow
2шт.
17351R1
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
BOLT, 3/8-16 C-Z hex.
4шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
16
495930R1
WEDGE
hay retainer wide
1шт.
18421R1
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd
2шт.
271501
SOCKET
NUT, 7/16-14 C-Z hex.
2шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
2шт.
17
STRIP, base plate wear, not for service, for service order 204017C92
2шт.
Long wear part.
1шт.
113225
RIVET,Csk, 3/16" x 9/16"
3/16 x 9/16 90 deg csk-hd
4шт.
18
FINGER ASSY, breast plate, 668975R12 replaced with 204631C91
2шт.
Long wear part.
1шт.
17064R1
LOCK PIN,1/8" x 5/8", Slotted
Pin, 1/8" x 5/8", Slotted
2шт.
104168
RIVET,Csk, 1/4" x 7/8"
4шт.
19
87414
LUBE NIPPLE,1/4" - 28
FITTING, 1/4-28 str self tap. lub
1шт.
20
674263R1
BUSHING
packer crank
3шт.
21
663364R1
BUSHING
packer crank
1шт.
22
674101R1
FILLER
knotter drive frame upper
1шт.
18779R1
BOLT,Hex, 3/8"-16 x 1 1/2", Gr 2
3/8 x 1-1/2 C-Z hex-hd mach
3шт.
120377
NUT,3/8" - 16, Gr 5
3шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
3шт.
20803R1
WASHER
13/32 x 1 x 16 ga C-Z
2шт.
204017C92
STRIP
BREAST PLATE WEAR STRIP PKG., consists of parts listed below
1шт.
PAD, breast plate wear, replaces strip, breast plate wear
2шт.
113225
RIVET,Csk, 3/16" x 9/16"
3/16 x 9/16 90 deg csk-hd solid
4шт.
