Запчасти Case IH 430 (E-30) - NEEDLES AND GUIDES, FOR WIRE BALERS, SERIAL NUMBER, 430W 50 IN. THRU 001193, 440W 50 IN. THRU 002159

Схема запчастей Case IH 430 - (E-30) - NEEDLES AND GUIDES, FOR WIRE BALERS, SERIAL NUMBER, 430W 50 IN. THRU 001193, 440W 50 IN. THRU 002159

Артикул

Название

Примечание

Количество

1

200539C2

WEDGE, needle brake

1шт.

18686R1

CARRIAGE BOLT,Short Nk, 3/8" - 16 x 2 1/4", Gr 2

BOLT, 3/8 x 2-1/4 znd sq-nk crg

4шт.

18422R1

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 2

BOLT, 3/8 x 1-3/4 znd sq-nk crg

4шт.

120377

NUT,3/8" - 16, Gr 5

8шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

619856R1

WASHER

13/32 x 1 x 16 ga C-Z, (or as required)

2шт.

2

674089R1

GUARD

needle

1шт.

17351R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2

BOLT, 3/8 x 1 znd sq-nk crg

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

18794R1

BOLT,Hex, 7/16" - 14 x 1", Gr 2

7/16 x 1 znd hex-hd mach

2шт.

271501

SOCKET

NUT, 7/16-14 znd hex.

2шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

607891R1

WASHER

15/32 x 1 x 16 ga C-Z

2шт.

3

660200R1

SPACER,10.7mm ID x 17.14mm OD x 9.5mm L

needle brake, replaces 22671R1

2шт.

4

(Not serviced separately), order 668023R91

1шт.

5

668025R1

LINING

needle rear brake

2шт.

136143

PIN

RIVET, tubular 3/16 x 7/16

10шт.

6

668023R91

BRAKE

needle cpt. rear

2шт.

7

665438R1

CLEVIS COUPLING

CONNECTOR, needle Pitman

1шт.

23269R1

PIN,3/4" x 1.910"

3/4 x 2-3/64 C-Z rod end

1шт.

137218

COTTER PIN,5/32" x 1 1/4"

PIN, SPLIT (COTTER), 5/32" x 1 1/4"

1шт.

8

664767R1

ROD, needle Pitman

1шт.

217216

NUT

1-14 znd hex.

1шт.

21757R1

WASHER

25/32 x 1-1/4 x 22 ga. C-Z

1шт.

187988

COTTER PIN,3/16" x 1 1/4"

PIN, SPLIT (COTTER), 3/16" x 1 1/4"

1шт.

9

667418R1

LINING

needle front brake

2шт.

136143

PIN

RIVET, tubular 3/16 x 7/16

10шт.

10

(Not serviced separately), order 667416R91

1шт.

11

667416R91

BRAKE

needle front cpt.

2шт.

12

664818R1

BUMPER

needle

2шт.

18780R1

BOLT,Hex, 3/8"-16 x 1 3/4", G2

3/8 x 1-3/4 znd hex-hd mach

2шт.

18779R1

BOLT,Hex, 3/8"-16 x 1 1/2", Gr 2

3/8 x 1-1/2 znd hex-hd mach

2шт.

120377

NUT,3/8" - 16, Gr 5

5шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

5шт.

469668R1

WASHER

13/32 x 3/4 x 16 ga C-Z

3шт.

19019R1

CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2

BOLT, 3/8 x 1 znd No. 3 plow

1шт.

13

665087R2

PLATE ASSY.

SUPPORT, needle bumper

2шт.

14

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.

15

664753R21

CRANK, needle w/bushing

1шт.

16

181620

SCREW,Hex, 5/16" - 24 x 2", Gr 5

BOLT, shear 5/16-24 x 2 znd hex-hd cap screw

1шт.

495-21031

WASHER,1/4"

NUT, 5/16-24 znd hex.

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

17

662555R1

BUSHING,8.46mm ID x 15.98mm OD x 12.83mm L

needle shear bolt

2шт.

18

663167R11

HUB

needle crank, w/bushing

1шт.

180191

BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5

SCREW, 1/2-13 x 3-1/4 znd hex-hd cap

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

1шт.

120384

WASHER,1/2"

LOCK, 1/2"

1шт.

19

200540C1

SHIELD

needle drive

1шт.

18508R1

CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd

BOLT, 3/8 x 3/4 znd sq-nk crg

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

20

664774R91

ARM

STRAP, needle pivot hammer cpt.

2шт.

18685R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1 1/2", Gr 2

BOLT, 3/8 x 1-1/2 znd sq-nk crg

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

21753R1

WASHER

25/32 x 1-1/2 x 16 ga, (or as required)

4шт.

21

664787R1

BUSHING

needle pivot

2шт.

22

664781R93

PIPE

needle tie, includes 2 ref. No. 21

1шт.

23

352133R1

PLATE

wire guide mounting

6шт.

436732

SCREW,Slotted Pan Hd, #10-24 x 1/2"

10-24 x 1/2 znd slt-pan-hd mach

12шт.

120361

NUT,Hex Mach Screw, #10 - 24

12шт.

120217

LOCK WASHER,#10

WASHER, LOCK, #10

12шт.

21784R1

WASHER

17/64 x 1/2 x 16 ga, (or as required)

12шт.

24

667411R11

NEEDLE

cpt., includes ref No. 25, 26, 27 and 28

2шт.

25

667414R1

BUSHING

needle tip

2шт.

26

667413R1

SPACER

PIECE, needle tip wearing

2шт.

27

667415R1

BUSHING

needle sheave

2шт.

102688

RIVET,Csk, 3/16" x 13/16"

csk. hd. 3/16 x 13/16

2шт.

102689

csk. hd. 1/4 x 13/16

2шт.

271562

SHIELD,Hex, 5/8" - 11 x 2", Gr 5

SCREW, 5/8-11 x 2 hex-hd cap

4шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

589068R1

WASHER

21/32 x 1-1/4 x 11 ga C-Z

4шт.

28

667412R1

ROLL

SHEAVE, wire needle

2шт.

29

670617R2

GUIDE

wire

6шт.

30

668811R1

SHIM, needle brake, (or as required)

2шт.

31

Q72

KEY,5/16" Sq x 1 7/8", Par

parallel, 3/8 x 1-7/8

1шт.

32

674704R1

SUPPORT

wire guide

1шт.

33

674703R

BRACKET, wire guide

2шт.

34

674099R1

WEDGE

hay

2шт.

15016R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1 1/8" , Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1 1/8", G2

4шт.

664646R1

LOCK NUT,7/16"-14, GB

NUT, 7/16-14 hex. lock

4шт.

35

668027R1

STRIP

wear

2шт.

88542

BOLT,Hex, 1/4"-20 x 1/2", Gr 5

SCREW, 1/4-20 x 1/2 znd hex-hd cap

4шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

36

87569

LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive

FITTING, 1/4-28 45 deg angle self tap. lub

1шт.

Выбрано товаров: 86
