Запчасти Case IH 428 (A-57[A]) - FOUR COIL WIRE CONTAINER FOR WIRE BALER

1

455346R21

PIN

ASSY, lock, consists of

1шт.

2

455347R1

VALVE SPRING

SPRING

1шт.

3

661406R1

LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk

X

1шт.

4

80711

LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg

FITTING, 1/8 PTF SHORT 65D lub

2шт.

5

568100R92

YOKE

ASSY, w/Q.A. pin, includes ref no. 1

1шт.

6

200464C91

PACKAGE

KIT, cross repair

2шт.

576420R1

RING

snap

8шт.

7

ZA550413

YOKE

& SHAFT ASSY, retangular

1шт.

8

ZA017169

RING, bearing retaining

2шт.

9

ZA550446

SHIELD

W/PRODUCT GRAPHIC, outer

1шт.

ZA017150

PRODUCT GRAPHIC, warning

1шт.

10

ZA550482

SHIELD

inner

1шт.

11

ZA017167

BEARING, shield

2шт.

12

19688R1

LUBE NIPPLE,1/4"-28 x .44" lg

FITTING, 1/4 UNF less ball check lub

1шт.

13

ZA550445

YOKE

& TUBE

1шт.

14

663101R92

YOKE

flanged

1шт.

15

87569

LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive

FITTING, 1/4 45D taper drive thd lub

2шт.

16

ZA550411

JOINT

ASSY, drive, tractor half

1шт.

17

ZA550412

JOINT

ASSY, drive, implement half

1шт.
