Запчасти Case IH 8575 (6-16) - KNOTTER TWINE FINGER AND HAY DOG ASSEMBLIES (14) - BALE CHAMBER

1

700124056

ROLLER

-CLUTCH

1шт.

2

100-1175

SNAP RING,#75, Ext

Ring, Snap, #75, Ext

2шт.

3

6525042

ROLLER,41.28mm OD x 12.5mm L

-CLUTCH

1шт.

4

413-1240

BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5

Hex, 3/4"-10 x 2-1/2", G5

1шт.

5

495-21081

WASHER,3/4"

1шт.

6

492-11075

LOCK WASHER,3/4"

3/4"

1шт.

7

425-1012

NUT,3/4"-10, G5

3/4-10 H

1шт.

8

700124053

ARM

WA

1шт.

9

700106397

SPACER

1шт.

10

434-616

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5

3/8-16 X 1 RHSNB

4шт.

11

492-11038

LOCK WASHER,3/8"

8шт.

12

425-106

NUT,3/8"-16, Cl 5

4шт.

13

111-361

CARRIAGE BOLT,Short NK, 3/8"-16 x 1 1/2", G5

BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/2", G5

4шт.

14

495-21044

WASHER,3/8"

4шт.

15

231-5146

FLANGE NUT,3/8"-16

12шт.

16

702400048

ROD

4шт.

17

409-7612

BOLT,3/8"-16 x 1.09" OAL

3/8-16 X 3/4 HFSS

4шт.

18

8044695

SEAL,15.37mm ID x 30.56mm OD x 1.96mm Thk

8шт.

19

700122681

BUSHING,10.34mm ID x 15.88mm OD x 19.18mm L

BUSHING

4шт.

20

700113345

FINGER

-TWINE

4шт.

21

S120261

PIN

.149 WIRE HAIRPIN COTTER

7шт.

22

213-126

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS, ADJUSTABLE, 3/8"-24 x 2 1/2"

4шт.

23

063586

CLEVIS PIN

3/8 X 1-1/8 CLEVIS PIN

4шт.

24

425-156

JAM NUT,Jam, 3/8"-24, G5

4шт.

25

6523740

ROD

-FINGER

4шт.

26

425-146

JAM NUT,3/8" - 16, Gr 5

4шт.

27

219-93

LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF

4шт.

28

432-812

COTTER PIN,3/4" OAL x 1/8" W

PIN, SPLIT (COTTER), 1/8" x 3/4"

4шт.

29

700122682

LARGE PLATE

PLATE-FINGER

4шт.

30

700706376

SPRING

-TORSION

3шт.

31

396-21066

WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk

- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN

6шт.

32

439-11060

HEADED PIN,15.88mm OD x 95.25mm L

5/8 X 3-3/4 CLEVIS PIN

3шт.

33

700113344

TRIPDOG

HAY DOG

3шт.

34

222-1676

ELBOW

90 DEGREE ELBOW-COMPRESSION

1шт.

35

6845929

LINE

-GREASE

1шт.

36

222-2101

ELBOW,90 Degree, Flareless, 5/16"-24 x 1/8 NPT

1/8 NPTF X 90 DEGREE ELBOW

1шт.

37

219-1

LUBE NIPPLE,1/8" - 27 NPTF

1/8 NPTF STRAIGHT ZERK

1шт.
