Запчасти Case IH 8575 (6-02) - KNOTTER FRAME ASSEMBLY (14) - BALE CHAMBER

1

413-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5

4шт.

2

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

6шт.

3

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

4шт.

4

495-21056

WASHER,1/2"

1/2 HARDENED PLAIN WASHER

2шт.

5

700123351

FUNNEL

FRAME WA-KNOTTER

1шт.

6

164-102

HEX SOC SCREW,FLAT, #10 - 32 x 1/2"

#10-32 X 1/2 HSFCHCS

4шт.

7

700707700

BALL BEARING,6.48 mm ID x 31.75 mm OD x 13.08 mm

ROLLER-BEARING

4шт.

8

866566

FASTENER,#10 - 32 x 9/16"

#10-32 FASTENER-SPECIAL

4шт.

9

700123374

ARM

ASM. (Includes Ref: 6, 7 & 8)

1шт.

10

858308

SPRING

-EXTENSION

1шт.

11

495-81205

WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk

1-1/4 X 18 GAUGE NRMB

13шт.

12

700113342

SUPPORT

-BEARING

2шт.

13

432-1028

COTTER PIN,5/32" x 1 3/4"

PIN, SPLIT (COTTER), 5/32" x 1 3/4"

2шт.

14

D23692

SNAP RING,#100, Ext, Crescent

Ring, Snap, #100, Ext, Crescent

2шт.

15

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 NPT x .54" lg

2шт.

16

195-2103

WASHER,1 1/16" x 1 1/2" x .065"

1 X 18 GAUGE NRMB

11шт.

17

219-90

LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF

1/4-28 X 45 DEGREE ZERK

2шт.

18

700123376

FUNNEL

FRAME WA-TENSION ARM

1шт.

19

758482

TENSION SPRING

SPRING-EXTENSION

4шт.

20

700712484

SPRING

-EXTENSION

1шт.

21

700714985

SPRING

-EXTENSION

1шт.

22

433-816

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5

1/2-13 X 1 RHSNB

4шт.

23

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

4шт.

24

219-17

LUBE NIPPLE,3/16" NPTF

NIPPLE, LUBE, , Push 3/16" x .55" lg, Drive

2шт.

25

425-118

NUT,1/2"-20, G5

1/2-20 H

2шт.

26

8050866

CAM FOLLOWER

ROLLER-CAM

2шт.

27

700123370

SHAFT

- TWINE FINGER

1шт.

28

700123381

ROD

-MONITORING

2шт.

29

6523799

BUSHING

4шт.

30

413-520

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

5/16-18 X 1-1/4 C

4шт.

31

495-61034

WASHER,0.34" ID x 0.88" OD x 0.06" Thk

5/16 WIDE PLAIN WASHER

4шт.

32

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

4шт.

33

425-105

NUT,5/16"-18, G5

4шт.
