Запчасти Case IH 8575 (4-04) - CONSOLE CONTROL BOX ASSEMBLY (06) - ELECTRICAL

1

700707294

PUSH-ON NUT

RUBBER WELL NUT

2шт.

2

51200165

SCREW,Hex, 1/4"-20 x 1", G5

1/4-20 X 1 C

3шт.

3

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

3шт.

4

425-104

NUT,1/4"-20, Cl 5

3шт.

5

700114077

SUPPORT

-CONTROL BOX

1шт.

6

700707378

KIT

SACK OF PARTS, Includes Items in art marked with Asterisk

1шт.

7

700707377

KIT

SACK OF PARTS, Includes Items in art marked with Asterisk

1шт.

8

700715031

CONSOLE

CONTROL BOX COMPLETE, (Includes Ref: 6, 7, 10, 11, 12, 13, 14, 21 and 22)

1шт.

9

700707295

KNOB

2шт.

10

700707457

BULB

LAMP AND HOLDER

3шт.

11

700707383

GASKET

-SPONGE CORD (BULK-10 FOOT)

1шт.

12

700707296

PANEL

COVER

1шт.

13

700711660

SEAL

1шт.

14

700712102

SEAL

1шт.

15

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

2шт.

16

700707598

WIRE HARNESS

CABLE ASSEMBLY (USED FROM CONTROLLER TO BATTERY)

1шт.

17

700712135

WIRE HARNESS

CABLE ASSEMBLY (USED FROM CONTROLLER TO AUXILIARY POWER SOURCE)

1шт.

18

700707382

REPAIR KIT

KIT-REPAIR

1шт.

19

700712134

REPAIR KIT

KIT-RECEPTACLE REPAIR

1шт.
