Запчасти Case IH 8545 (2-18) - DRIVE ASSEMBLY (PICKUP) Driveline

1

T27207

FLANGED BEARING

FLANGE - bearing

2шт.

2

565672R92

SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"

BEARING - spherical

1шт.

3

434-616

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5

3/8-16 X 1 RHSNB

3шт.

4

492-11038

LOCK WASHER,3/8"

3шт.

5

425-106

NUT,3/8"-16, Cl 5

3шт.

6

7884950

BOLT

7/16-14 X 2-1/8 C

1шт.

7

429-107

NUT,7/16"-14, G8

1шт.

8

328-824

BOLT,Hex, 1/2" - 20 x 1-1/2", Gr 8

3шт.

9

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

4шт.

10

700119299

ARM

(Includes item 11)

1шт.

11

7852718

SLEEVE

- shear

1шт.

12

700119476

BRONZE BUSHING

BUSHING - bronze

1шт.

13

219-90

LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF

1/4-28 X 45 DEGREE ZERK

1шт.

14

700119301

SPROCKET

ASSEMBLY - 44 tooth (Includes items 12 and 15)

1шт.

15

700112222

SLEEVE

- shear

1шт.

16

700112234

ANGLE

1шт.

17

7770787

FITTING,Sq Nk, 1/2" - 13 x 4", Gr 5, Full Thd

1/2-13 X 4 FTRHSNB

1шт.

18

425-148

JAM NUT,Jam, 1/2"-13, G5

1шт.

19

433-1044

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 3/4", Gr 5

5/8-11 X 2-3/4 RHSNB

1шт.

20

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

21

425-1010

NUT,5/8"-11, G5

1шт.

22

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

1шт.

23

495-21056

WASHER,1/2"

1/2 HARDENED PLAIN WASHER

1шт.

24

396-21066

WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk

- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN

3шт.

25

629972R91

DRIVE SPROCKET,15T

SPROCKET - idler, 15 tooth

1шт.

26

700709036

LINK

- connector, high strength, #60 R/C with pins

1шт.

27

700709038

CHAIN

- roller, #60 high strength (10 foot bulk)

1шт.

28

700119298

SHIELD

- shaft

1шт.

29

6521868

BOLT

SHEAR BOLT KIT - packaged: (Includes 10 each of items 6 and 7)

1шт.
