Запчасти Case IH 8545 (6-26) - TWISTER CONTROL ASSEMBLY (WIRE) (14) - BALE CHAMBER

1

6553556

BRACKET

BRAKE - half, right (Includes items 4 & 5)

1шт.

2

6553572

BRAKE LINING

BRAKE - half, left (Includes items 4 & 5)

1шт.

3

7758154

SPRING

- compression

2шт.

4

700711021

BRAKE LINING

LINING - brake

2шт.

5

64980

RIVET

- aluminum

6шт.

6

700119418

FUNNEL

FRAME WA - twister

1шт.

7

111-237

CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5

BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5

2шт.

8

495-61034

WASHER,0.34" ID x 0.88" OD x 0.06" Thk

5/16 WIDE PLAIN WASHER

2шт.

9

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

5шт.

10

425-105

NUT,5/16"-18, G5

5шт.

11

700705653

SHIELD

- slot

2шт.

12

700108418

WASHER

- special

1шт.

13

700703778

BUMPER

1шт.

14

413-864

BOLT,Hex, 1/2" - 13 x 4", Gr 5

1/2-13 X 4 C

1шт.

15

230-4118

LOCK NUT,1/2"-13, GA

1/2-13 HTLN GR/B

1шт.

16

700707863

SPRING

- torsion

1шт.

17

700117281

DRIVE DOG

HAY DOG

1шт.

18

204807C91

BEARING ASSY,25.4mm ID x 52mm OD x 15mm W

BEARING - spherical

1шт.

19

51200380

FLANGE

- bearing

2шт.

20

433-512

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5

3шт.

21

413-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5

1шт.

22

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

5шт.

23

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

5шт.

24

700119424

SUPPORT

- idler

1шт.

25

47977

SPROCKET ASSY.

SPROCKET - idler, 18 tooth

1шт.

26

433-820

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 X 1-1/4 RHSNB

4шт.

27

495-21056

WASHER,1/2"

1/2 HARDENED PLAIN WASHER

4шт.

28

1790D

CHAIN (AG)

CHAIN - roller, #40 (10 foot bulk)

1шт.

29

1301D

CHAIN LINK

LINK - connector, #40 R/C

1шт.

30

434-616

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5

3/8-16 X 1 RHSNB

2шт.

31

496-11041

WASHER,13/32" x 13/16" x .065", HDN

3/8 HARDENED PLAIN WASHER

2шт.

32

492-11038

LOCK WASHER,3/8"

2шт.

33

425-106

NUT,3/8"-16, Cl 5

4шт.

34

413-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 5

C Hex, 5/8"-11 x 2", G5

1шт.

35

396-21066

WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk

- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN

3шт.

36

492-1102

5/8 L

1шт.

37

425-1010

NUT,5/8"-11, G5

1шт.

38

111-360

CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5

BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5

3шт.

39

231-5146

FLANGE NUT,3/8"-16

3шт.

40

413-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

2шт.

41

232-5316

FLANGE NUT,Flg, 3/8"-16

3/8-16 HFTLN GR/G

2шт.

42

433-440

CARRIAGE BOLT,Sq Nk, 1/4" - 20 x 2 1/2", Gr 5

1/4-20 X 2-1/2 RHSNB

2шт.

43

496-11028

WASHER,9/32" x 5/8" x .065, HDN

1/4 HARDENED PLAIN WASHER

2шт.

44

230-4214

LOCK NUT,1/4"-20, GA

NUT, LOCK, 1/4"-20, GA

2шт.
