Запчасти Case IH 8540 (34) - WIRE TWISTER ASSEMBLY (14) - BALE CHAMBER

1

77818

FITTING

1/4-28 zerk

2шт.

2

6859300

FRAME

SHUTTLE FRAME

1шт.

3

6853105

MOUNTING PARTS

PIVOT MOUNTING, shuttle

2шт.

4

6853469

JACK

NO. 18 JACK CHAIN

1шт.

5

7058993

SPRING

1шт.

6

7894470

COUNTER

bale

1шт.

7

6853451

BRACKET

1шт.

8

766543

SCREW

5/16-18 thread

2шт.

9

7745003

GUIDE

FERRULE

2шт.

10

6859532

BRACKET

wire guide

2шт.

11

6560437

NEEDLE

wire

2шт.

12

6560403

SPACER

1/4 I.D. x 3/8" long

2шт.

13

7053739

ROLLER

wire guide

6шт.

14

863753

PIN

5/8 x 1-3/4 clevis pin

1шт.

15

77065

LUBE NIPPLE,1/8"-27 x .66 lg

1/8-27 x 11/16 special zerk

1шт.

16

7746472

CONNECTOR, ELEC

1/8 NPTF x 3/8 tube port M/F connector

2шт.

17

2700077

LINE

GREASE, 3/8" O.D.

1шт.

18

7746464

ELBOW

1/4-28 x 1/8 NPTF M/F x 90deg. elbow

1шт.

19

762435

LOCK PIN,1/2" x 3", Slotted

Pin, 1/2" x 3", Slotted

1шт.

20

6853535

PLUNGER

STOP, plunger

1шт.

21

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 NPT x .54" lg

2шт.

22

6859524

BRACKET

GUIDE BRACKET, right, set of right and left

2шт.

23

6859516

BRACKET

GUIDE BRACKET, left, set of right and left

2шт.

700120981

BRACKET

GUIDE BRACKET, right, set of right and left (S.N. CFH - 0021237 and later)

2шт.

700120933

BRACKET

GUIDE BRACKET, left, set of right and left (S.N. CFH - 0021237 and later)

2шт.

24

6560346

SPACER

5/8 O.D. x 13/32" long

4шт.

25

700101199

GUIDE

wire, left

2шт.

26

7053721

ROLLER

2шт.

27

700101198

GUIDE

wire, right

2шт.

28

6850689

BLOCK

SUPPORT BLOCK

1шт.

29

6853493

ARM/LIFTING DEVICE

ARM, plunger stop

1шт.

30

758110

SPRING

1шт.

31

63685

BELT, TRANSMISSION

1/2 x 1-1/2 clevis pin

1шт.

32

866236

CLEVIS COUPLING

CLEVIS

1шт.

33

700101205

LINK

ROD, stop, plunger

1шт.

34

700101203

BUSHING

19/32" I.D. x 7/32" long

1шт.

35

700101202

STOP

arm, plunger

1шт.

36

758268

SPRING

1шт.

37

52761

BUSHING

3/4 x 14 gauge machinery bushing

1шт.

38

6554034

BUSHING

1" O.D. x 1-1/4" long

1шт.

39

7758980

SPRING

1шт.

40

2401522

ANGLE

2шт.

41

6853675

ROD

1шт.

42

866228

CLEVIS COUPLING

CLEVIS

1шт.

43

273508

SHIELD

4шт.

44

1661175

COVER

2шт.

45

7714660

ROLLER ASSY.

ROLLER, wire guide

4шт.

51200165

SCREW,Hex, 1/4"-20 x 1", G5

1/4-20 x 1 hex cap screw grade 5

4шт.

61-42512

HEX SOC SCREW,Flat Hd, 1/4"-20 x 3/4"

1/4-20 x 3/4 hex socket flat head cap screw grade 5

2шт.

7703499

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16-18 x 3/4 hex cap screw grade 5

8шт.

703579

BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd

5/16-18 x 1 hex cap screw grade 5

8шт.

873125

BOLT,Hex, 3/8" - 16 x 2", Gr 5

3/8-16 x 2 full thread hex cap screw grade 5

1шт.

701771

SUPPORT

5/8-11 x 2-1/4 round head square neck bolt grade 5

1шт.

700013

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5

5/16-18 x 3/4 round head square neck bolt grade 5

5шт.

7700578

CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1", Gr 5

5/16-18 x 1 round head square neck bolt grade 5

20шт.

700047

BOLT

3/8-16 x 1 round head square neck bolt grade 5

8шт.

700054

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5

3/8-16 x 1-1/4 round head square neck bolt grade 5

2шт.

703223

BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5

1/2-13 x 4-1/2 hex cap screw grade 5

2шт.

702217

SHIELD

1/2-13 x 4 hex cap screw grade 5

2шт.

7701188

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 x 1-1/4 hex cap screw grade 5

1шт.

7870546

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 3/4", Gr 5

1/2-13 x 1-3/4 round head square neck bolt grade 5

1шт.

7700156

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5

1/2-13 x 1-1/2 round head square neck bolt grade 5

2шт.

707018

BOLT,#3, 3/8" - 16 x 1 1/4", Gr 5

3/8-16 x 1-1/4 plow bolt grade 5

2шт.

704619

SUPPORT

5/16-18 hex center lock nut

14шт.

704288

LOCK NUT

1/2-13 hex center lock nut

3шт.

705723

WASHER

3/4 narrow plain washer

4шт.

705681

WASHER,1", SAE

1 narrow plain washer

3шт.

430-4214

1/4-20 hex center lock nut

5шт.
