Запчасти Case IH 8540 (28) - TWINE KNOTTER ASSEMBLY (14) - BALE CHAMBER

1

6853931

BRACKET

GUIDE BRACKET

2шт.

2

762435

LOCK PIN,1/2" x 3", Slotted

Pin, 1/2" x 3", Slotted

1шт.

3

6853535

PLUNGER

STOP, plunger

1шт.

4

6853493

ARM/LIFTING DEVICE

ARM

1шт.

5

758110

SPRING

1шт.

6

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 NPT x .54" lg

1шт.

7

866236

CLEVIS COUPLING

YOKE END

1шт.

8

NLS

NO LONGER SERVICED

1/2 x 1-1/2 clevis pin

1шт.

9

700101205

LINK

ROD, stop, plunger

1шт.

10

700101203

BUSHING

19/32 I.D. x 7/32" long

1шт.

11

700101202

STOP

arm, plunger

1шт.

12

700101201

SHIELD

needle slot

1шт.

13

6553614

SPACER

1/4" long

2шт.

14

6553606

MOUNTING PARTS

PLATE, mounting

2шт.

15

66498

CLEVIS

2шт.

16

700101883

ROD

2шт.

17

6853485

FINGER

2шт.

18

77818

FITTING

1/4-28 zerk, spin drive thread

2шт.

19

7746472

CONNECTOR, ELEC

1/8 NPTF x 3/8 tube port M/F connector

1шт.

20

6853196

FRAME ASSY

SHUTTLE FRAME

1шт.

21

6853469

JACK

#18 JACK CHAIN

1шт.

22

758268

SPRING

tension

1шт.

23

2700077

LINE

GREASE

1шт.

24

6853287

KNOTTER

BRACKET, knotter

2шт.

25

763300

CLEVIS PIN

5/16 x 1 clevis pin

2шт.

26

6850689

BLOCK

SUPPORT BLOCK

1шт.

27

7758980

SPRING

tension

1шт.

28

7058993

SPRING

1шт.

29

7894470

COUNTER

bale

1шт.

30

6853451

BRACKET

1шт.

31

7745003

GUIDE

FERRULE

6шт.

32

51200861

U-BOLT

5/16-18 thread

6шт.

33

6853675

ROD

1шт.

34

863753

PIN

5/8 x 1-3/4 clevis pin

1шт.

35

730804

DOWEL,1/4" x 1/2"

PIN

4шт.

36

6554034

BUSHING

1-1/4" long

1шт.

37

6853105

MOUNTING PARTS

PIVOT MOUNTING, shuttle

2шт.

38

866228

CLEVIS COUPLING

CLEVIS

1шт.

39

1661235

NEEDLE

twine

2шт.

40

95-81182

WASHER,0.81" ID x 1.25" OD x 0.07" Thk

3/4 x 14 gauge machinery bushing

1шт.

41

77065

LUBE NIPPLE,1/8"-27 x .66 lg

1/8-27 x 11/16 special zerk

1шт.

42

51200254

WASHER

4шт.

43

7746464

ELBOW

1/4-28 x 1/8 NPTF M/F x 90deg. elbow

1шт.

701235

BOLT,1/2" - 13 x 1 1/2", Gr 5

1/2-13 x 1-1/2 hex cap screw grade 5

2шт.

873380

SCREW,Hex, 1/2" - 13 x 2", Full Thd

1/2-13 x 2 full thread hex cap screw grade 5

1шт.

7772049

BOLT,Hex Serr, 5/16" - 18 x 1"

5/16-18 x 1 hex flange serrated screw

8шт.

7884414

CAPSCREW,Button Hd, 3/8" - 16 x 1", Gr 8

3/8-16 x 1 hex socket button head cap screw grade 5

2шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8-11 x 2-1/4 hex cap screw grade 5

1шт.

700013

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5

5/16-18 x 3/4 round head square neck bolt grade 5

9шт.

7700578

CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1", Gr 5

5/16-18 x 1 round head square neck bolt grade 5

4шт.

7700065

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5

3/8-16 x 3/4 round head square neck bolt grade 5

4шт.

700047

BOLT

3/8-16 x 1 round head square neck bolt grade 5

4шт.

700054

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5

3/8-16 x 1-1/4 round head square neck bolt grade 5

2шт.

7700156

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5

1/2-13 x 1-1/2 round head square neck bolt grade 5

2шт.

7701188

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 x 1-1/4 hex cap screw grade 5

1шт.

703223

BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5

1/2-13 x 4-1/2 hex cap screw grade 5

2шт.

413-864

BOLT,Hex, 1/2" - 13 x 4", Gr 5

1/2-13 x 4 hex cap screw grade 5

2шт.

707018

BOLT,#3, 3/8" - 16 x 1 1/4", Gr 5

3/8-16 x 1-1/4 plow bolt grade 5

2шт.

230-4215

NUT,5/16"-18, GA

5/16-18 hex center lock nut

14шт.

704288

LOCK NUT

1/2-13 hex center lock nut

4шт.

495-11081

WASHER,3/4", SAE

3/4 narrow plain washer

5шт.

705681

WASHER,1", SAE

1" narrow plain washer

3шт.
