Запчасти Case IH 8540 (12) - PRIMARY DRIVE ASSEMBLY Driveline
№
Артикул
Название
Примечание
Количество
1
50583
FLANGED BEARING
bearing
2шт.
2
51318
BEARING
SPHERICAL BEARING
1шт.
3
2401461
MOUNTING PARTS
MOUNT, bearing
1шт.
4
2401462
SPROCKET ASSY.
SPROCKET, 80-pitch, 35 tooth
1шт.
5
6855225
CLEVIS
STRAP
1шт.
6
6541833
BUSHING
BRONZE BUSHING, 2-3/4 ID x 1-1/2" long
1шт.
7
61879
KEY
1/2 x 1/2 x 2-1/2 key
2шт.
8
51200254
WASHER
1шт.
10
337527
SPACER
13/16 x 17/32" long
2шт.
11
51200277
SPROCKET ASSY.
IDLER SPROCKET, 80-pitch, 12 tooth
1шт.
12
6855456
WASHER
1шт.
13
6855746
SPROCKET ASSY.
SPROCKET ASSEMBLY, 80-pitch, 40-tooth, (includes sleeve and bushing)
1шт.
14
6855704
WASHER
SPROCKET WITH SPLINED HUB, 50-pitch, 40-tooth, (includes sleeve)
1шт.
15
8746638
PLUG
magnetic
1шт.
16
6855548
FLYWHEEL WITH GEAR
FLYWHEEL ASSEMBLY (includes sleeve and bushings)
1шт.
17
6855530
ARM
shear bolt
1шт.
18
761122
KEY
5/16 x 5/16 x 2 key
2шт.
19
6855431
SHIELD
shaft (PVC pipe)
1шт.
20
712307
BEARING
SPHERICAL BEARING
1шт.
21
825620C1
RETAINER
FLANGE, bearing
2шт.
22
6855241
MOUNTING PARTS
MOUNT, bearing
1шт.
23
2401470
SHAFT
DRIVE SHAFT, primary
1шт.
24
6855555
SLEEVE
shear
1шт.
25
6855423
WASHER
1шт.
26
87569
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
1/4-28 x 45deg. zerk
1шт.
27
8052052
BRONZE BUSHING
1-5/8 ID x 1-3/4 long
2шт.
28
6855373
CRANK
1шт.
29
6855449
WASHER
special
1шт.
30
8744047
SEAL
grease
1шт.
31
6855472
BEARING HOUSING
BEARING HOUSING
1шт.
32
8051005
ROLLER BEARING,55mm ID x 100mm OD x 25mm W
CYLINDRICAL ROLLER BEARING
1шт.
33
8052326
RING
RETAINER RING
1шт.
34
8744054
SEAL
dust
1шт.
35
219-8
LUBE NIPPLE,1/4" - 28 NPTF
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg
1шт.
36
7751605
BREATHER
AIR VENT
1шт.
37
803783
REDUCER
3/4-10 NPTF x 1/8 NPTF M/F bushing
1шт.
38
6855845
PLATE
LOCK TAB
2шт.
39
6855563
GEARBOX ASSY
GEARBOX
1шт.
40
6855779
SLEEVE
shear 7/16 ID
1шт.
41
8029738
SLIDE
chain
1шт.
42
6855837
SLEEVE
shear 7/16 ID
1шт.
703249
BOLT,Hex, 3/8" - 16 x 1", Gr 5
3/8-16 x 1 hex cap screw grade 5
3шт.
7701188
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
1/2-13 x 1-1/4 hex cap screw grade 5
4шт.
8701971
SCREW,Hex, 1/2" - 13 x 2", Gr 5
1/2-13 x 2 left hand hex cap screw grade 5
1шт.
7701675
BOLT,Hex, 1/2" - 13 x 2", Gr 5
1/2-13 x 2 hex cap screw grade 5
1шт.
7702038
SCREW,Hex, 1/2" - 13 x 3", Gr 5
1/2-13 x 3 hex cap screw grade 5
2шт.
2700064
SCREW
1/2-13 x 4-1/2 full thread hex cap screw grade 5
2шт.
2700065
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 8
1/2-13 x 6 full thread hex cap screw grade 8
2шт.
7701758
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 5
5/8-11 x 1/2 hex cap screw grade 5
10шт.
7701956
BOLT
7/16-14 x 2-1/2 hex cap screw grade 5 (shear bolt)
1шт.
7770480
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3", Gr 5
3/8-16 x 3 round head square neck bolt grade 5
2шт.
7700248
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 5
1/2-13 x 2 round head square neck bolt grade 5
1шт.
2700063
HARDWARE,Sq Nk, 3/4" - 10 x 3 1/2", Gr 5, Full Thd
3/4-10 x 3-1/2 full thread round head square neck bolt grade 5
1шт.
433-816
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
1/2-13 x 1 round head square neck bolt grade 5
4шт.
7701899
BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5
3/8-16 x 2-1/2 hex cap screw grade 5 (shear bolt)
1шт.
7770514
FITTING,3/8" - 16 x 3 1/2", Gr 5, Full Thd
3/8-16 x 3-1/2 full thread round head square neck bolt grade 5
1шт.
69203
SET SCREW,Sq Hd, 3/8"-16 x 3/4"
3/8-16 x 3/4 cup point square head set screw grade 5
1шт.
69211
SET SCREW,Sq Hd, 3/8"-16 x 1"
3/8-16 x 1 cup point square head set screw grade 5
4шт.
231-4116
NUT,3/8"-16, GB
3/8-16 hex top lock nut
1шт.
704635
NUT
3/8-16 hex center lock nut
1шт.
7704059
LOCK NUT
7/16-14 hex center lock nut
1шт.
705624
TAPPET
1/2 narrow plain washer
1шт.
495-11081
WASHER,3/4", SAE
3/4 narrow plain washer
1шт.
705681
WASHER,1", SAE
1 narrow plain washer
1шт.
Выбрано товаров: 66
