Запчасти Case IH 8520 (9-36) - BALE THROWER CHUTE ASSEMBLY - UPPER Decals & Attachments

1

433-816

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5

1/2-13 X 1 RHSNB

2шт.

2

705541

WASHER,0.53" ID x 1.06" OD x 0.14" Thk

1/2 HARDENED PLAIN WASHER

6шт.

3

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

4шт.

4

704031

NUT

1/2-13 H

10шт.

5

768226

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5

1/2-13 X 1-3/4 RHSNB

2шт.

6

700047

BOLT

3/8-16 X 1 RHSNB

16шт.

7

705038

CONTROL VALVE

3/8"

16шт.

8

704023

NUT,3/8"-16, G5

3/8-16 H

16шт.

9

700112634

SUPPORT

- bearing, left

1шт.

10

51417

PIPE

- bearing

8шт.

11

51292

SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm

- spherical

4шт.

12

113985

1/2-13 DRAWBOLT

2шт.

13

700121569

ROLLER

- belt, lower

1шт.

14

700112645

FRAME

WA - thrower, upper

1шт.

15

700706359

PULLEY

SHEAVE - drive

1шт.

16

61069

KEY

1/4 X 1/4 X 1 KEY

1шт.

17

700111614

FLYWHEEL

1шт.

18

061978

KEY

1/4 X 1/4 X 2-1/2 GIB KEY

1шт.

19

69195

SET

3/8-16 X 1/2 CPSQHSS

2шт.

20

700112661

SUPPORT

- bearing, right

1шт.

21

700110303

SUPPORT

- mounting, tube

2шт.

22

52886

WASHER

1/2 X 14 GA. NRMB

8шт.

23

700121907

PLUG,44.45 mm OD, 330.2 mm Length

ROLLER WA - tube

1шт.

24

6556898

SHAFT

- roller

1шт.

25

7714611

ROLLER BEARING,17 mm ID x 40 mm OD x 12 mm

- radial

2шт.

26

700707322

LATCH ASSY.

FASTENER - smartloc

2шт.

27

828194

BELT,12.0" W

Conveyor 12.0" W

1шт.

28

700711329

PIN

- lacing

1шт.

29

700121568

ROLLER

WA - driven, upper

1шт.
