Запчасти Case IH RS561A (6-022) - TWINE THREADER ASSEMBLY (14) - BALE CHAMBER

1

700132687

SUPPORT

WA, twine arm, includes: REF. 6

1шт.

2

413-524

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

1шт.

3

230-4115

LOCK NUT,5/16"-18, GA

5/16"-18, hex. top lock, GR/B

1шт.

4

700135662

SHAFT

WA

1шт.

5

219-93

LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF

2шт.

6

740514

BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L

BEARING bronze

4шт.

7

495-81205

WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk

GAUGE 1-1/4" x 14, narrow rim machinery bushing

4шт.

8

103-11125

SNAP RING,#125, Ext

2шт.

9

700710984

SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC

4шт.

10

231-5348

FLANGE NUT,Flg, 1/2"-13

1/2"-13, hex. flange top lock, GR/G

4шт.

11

433-612

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5

4шт.

12

496-81010

WASHER

3/8", hardened, wide, plain

4шт.

13

231-5146

FLANGE NUT,3/8"-16

4шт.

14

700135773

PLATE

1шт.
