Запчасти Case IH RBX463 (14.16) - STARTER ROLL & RAKE, STUFFER FEEDER (14) - BALE CHAMBER

1

86640870

RAKE

1шт.

2

86635406

ROLL

Starter

1шт.

3

811-10040

CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8

2шт.

4

711-10030

CARRIAGE BOLT,Sq Nk, M10 x 1.5 x 30mm, Cl 8.8

2шт.

5

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.

6

825-2410

FLANGE NUT,M10 x 1.5, Flg, Cl 8

4шт.

7

122889

SHIM

.015"

4шт.

8

86978603

BEARING ASSY,45mm ID x 85mm OD x 22mm W

& Collar

2шт.

P.I.N. Y6N016414 & After

1шт.

9

86837676

FLANGED BEARING

4шт.

P.I.N. Y6N016414 & After

1шт.

10

86610638

BEARING ASSY,45mm ID

2шт.

Prior to P.I.N. Y6N016413

1шт.
