Запчасти Case IH RB565 (60.220.AU[07]) - VAR - 726822 - PICK-UP WHEEL ASSY, NO TOOLS, STANDARD PICKUP (60) - PRODUCT FEEDING

1

84193264

SUPPORT

2шт.

2

0C

ORDER COMPONENTS

Pickup Wheel

2шт.

3

84337334

CHANNEL

2шт.

4

270184

LINCH PIN,6.35mm OD

Klik

2шт.

5

87056822

PIN

Klik

2шт.

6

84220857

SPACER,12.7mm ID x 25.4mm OD x 70.5mm L

2шт.

7

9511052

WASHER,13.5mm ID x 44mm OD x 4mm Thk

4шт.

8

86508581

BOLT,Hex, M12 x 90mm, Cl 8.8

2шт.

9

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

2шт.

10

9706685

NUT,M12 x 1.75, Cl 8

2шт.

11

80756

COTTER PIN,1/8" x 3/4"

2шт.

12

47431237

WIRE ROPE

2шт.

13

84012277

KEY RING

2шт.
