Запчасти Case IH RB465 (90.105.BR[02]) - VAR - 726964 - TWINE BOX - TWINE AND NET OPTION, YFN188619 AND AFTER (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84580511

TENSIONER

1шт.

2

9820171

BRACKET

2шт.

3

84572188

DIVIDER

6шт.

4

133095

SPACER,10.32mm ID x 15.85mm OD x 7.9mm L

2шт.

5

86633356

CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8

2шт.

6

9804278

FLANGE NUT,M10 x 1.5, Cl 8

2шт.

7

86511840

BOLT,Hex Flng, M6 x 1 x 40mm, Cl 8.8

4шт.

8

29840

SPRING,Compression, 11.91mm OD x 25.4mm L

4шт.

9

80701

WASHER,0.31" ID x 0.73" OD x 0.07" Thk

4шт.

10

353308

NUT,M6 x 1.0, Cl 8

4шт.

11

86512444

CARRIAGE BOLT,M8 x 1.25 x 40mm, Full Thd, Cl 8.8

2шт.

12

27695

BUSHING,9.53mm ID x 12.83mm OD x 25.4mm L

2шт.

13

32379

SPRING,Extension, 1-1/4" OD x 5-3/8" L

2шт.

14

80664

WASHER,0.38" ID x 0.88" OD x 0.08" Thk

2шт.

15

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

2шт.

16

48113983

Porcelain

GUIDE

2шт.

17

48097944

U-BOLT

2шт.

18

322356

BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk

4шт.

19

87304

NUT,#10-24

4шт.
