Запчасти Case IH RB465 (68.180.BO[03]) - TWINE PIVOT ELECTRIC (68) - TYING/WRAPPING

1

84308004

HUB

1шт.

2

84279849

ACTUATING PLATE

1шт.

3

47441445

WIPER MOTOR,12V

Twine Pivot

1шт.

4

84258225

SPROCKET,RC35, 11T

1шт.

5

86977396

POTENTIOMETER,3000 Ohm, 16 VDC

1шт.

6

86000439

SNAP RING,0.288" ID x 0.66" OD x 0.037" Thk, External

1шт.

7

412255

BOLT,Hex, M4 x 20mm, Cl 8.8

2шт.

8

86505868

SERRATED NUT,Hex, M8 x 1.25, Cl 8

1шт.

9

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

5шт.

10

84300445

MOUNT

1шт.

11

9804276

FLANGE NUT,Hex, M6 x 1, Cl 8

2шт.

12

9672521

LOCK WASHER,Ext Tooth, #10

2шт.

13

86613601

WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk

1шт.

14

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

3шт.
