Запчасти Case IH 2400 (B-25) - TWINE SYSTEM (68) - TYING/WRAPPING

Схема запчастей Case IH 2400 - (B-25) - TWINE SYSTEM (68) - TYING/WRAPPING

Артикул

Название

Примечание

Количество

1

218382C1

KNIFE SECTION

BLADE, twine cutting

1шт.

18626R1

CARRIAGE BOLT,Short Sq Nk, 1/4" - 20 x 1/2", Gr 2

BOLT, 1/4 x 1/2 crg type 1

2шт.

938016R1

FLANGE NUT,Flg, USR, 1/4"-20

1/4 flange lock

2шт.

2

214493C1

SUPPORT

twine knife

1шт.

16897R1

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd

BOLT, 5/16 x 3/4 crg type 1

2шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16-18 znd hex. lock

2шт.

3

210318C1

SPRING

twine hook return

1шт.

4

214432C1

SUPPORT ASSY.

SUPPORT, twine tension

1шт.

18494R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 znd hex-hd mach

2шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8-16 znd hex. lock

2шт.

5

208688C1

SUPPORT

ASSY, twine hook

1шт.

6

208692C2

HOOK

ASSY, twine

1шт.

603632R1

HEADED PIN,9.53mm OD x 76.2mm L

PIN, 3/8 x 3. pln hd type 5

1шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

1шт.

7

208698C1

ROD

twine hook control

1шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

2шт.

8

210327C1

DEFLECTOR

hay twine hook

1шт.

9

87414

LUBE NIPPLE,1/4" - 28

FITTING, 1/4-28 self-tap lub

1шт.

10

208669C1

PULLEY

twine arm rope

3шт.

11

512749R1

HOOK

S-HOOK

4шт.

12

668048R1

CLIP

s-hook spring

2шт.

NLS

NO LONGER SERVICED

.469 x .922 x .051 znd

1шт.

13

208587C1

ROPE

twine feed arm

1шт.

22264R1

WASHER

.406 x 1.000 x .164 znd

1шт.

453231R1

WASHER

.406 x 1.750 x .105, used with remote electric twine system

1шт.

14

208583C2

ARM

ASSY, twine feed

1шт.

120376

NUT,5/16"-18, G5

2шт.

131016

WASHER

.656 x 1.312 x .074

2шт.

103397

COTTER PIN,5/32" x 1 1/4"

Pin, Split (Cotter), 5/32" x 1 1/4"

1шт.

15

213506C1

SPRING

twine arm return

1шт.

16

CHAIN, twine arm return, for service use 5 links from 10 ft. roll marked 560089R91 w/one 1310D connecting link

1шт.

1310D

LINK

#50 single pitch connecting

1шт.

17

210326C1

HANDLE

twine tube control rope

1шт.

18

208645C1

BRACKET, twine guide mounting

1шт.

19

208742C1

PLATE

twine arm indicator

1шт.

436732

SCREW,Slotted Pan Hd, #10-24 x 1/2"

10-24 x 1/2 znd pan-hd-clt & cross recess mach

2шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 znd hex. lock

2шт.

20

208330C1

BRACE

twine arm support

1шт.

18494R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 znd hex-hd. mach

5шт.

18495R1

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2

3/8 x 1-1/4 znd hex-hd. mach

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8-16 znd hex. lock

6шт.

21

208580C1

SUPPORT

ASSY, twine feed arm

1шт.

18778R1

SCREW,Hex, 3/8"-16 x 3/4", G2

BOLT, 3/8 x 3/4 znd hex-hd mach

2шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8-16 znd hex. lock

2шт.

22

670617R2

GUIDE

twine

2шт.

23

352133R1

PLATE

twine guide mounting

2шт.

436732

SCREW,Slotted Pan Hd, #10-24 x 1/2"

10-24 x 1/2 znd slt-pan-hd mach

4шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 C-Z flange lock

4шт.

24

208643C1

STOP

twin tube limit

1шт.

25

208746C1

ARM

ASSY, twine hook actuator

1шт.

26

208575C2

HOUSING

BOX ASSY, twine

1шт.

18764R1

HARDWARE,Hex, 5/16"-18 x 3/4", G2

BOLT, 5/16 x 3/4 type 1

7шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

7шт.

27

(Not used in this application)

1шт.

28

669184R1

CLAMP

CLIP, spring

1шт.

436732

SCREW,Slotted Pan Hd, #10-24 x 1/2"

10-24 x 1/2 znd slt-pan-hd mach

2шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 znd hex lock

2шт.

29

210452C1

ELBOW

ASSY, twine guide

1шт.

436732

SCREW,Slotted Pan Hd, #10-24 x 1/2"

10-24 x 1/2 znd slt-pan-hd mach

2шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 znd hex. lock

2шт.

30

670628R1

HINGE

twine box top

2шт.

436732

SCREW,Slotted Pan Hd, #10-24 x 1/2"

10-24 x 1/2 znd slt-pan hd

4шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 C-Z flange lock

4шт.

31

208579C1

COVER ASSY

TOP, twine box

1шт.

32

662380R1

GUIDE

PLATE, twine tension

2шт.

33

2064A

SPRING

twine tension

2шт.

18634R1

BOLT

1/4 x 2-3/4 crg type 1

2шт.

86627130

WING NUT,1/4"-20

NUT, 1/4 wing

2шт.

120392

WASHER,1/4", SAE

.281 x .625 x .051

2шт.

12653R1

BOLT (SPREADER),Short NK, 1/4"-20 x 3/4", G2

BOLT, CARRIAGE, Short NK, 1/4"-20 x 3/4", G2

2шт.

938016R1

FLANGE NUT,Flg, USR, 1/4"-20

1/4 flange lock

2шт.

Выбрано товаров: 71
