Запчасти Case IH 8465 (2-14) - CLUTCH CONTROL ASSEMBLY, DRIVE SHAFT Driveline

1

700116072

SHIM

8шт.

2

700116071

SPACER

3шт.

3

413-672

BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5

3/8-16 X 4-1/2 C

3шт.

4

496-11041

WASHER,13/32" x 13/16" x .065", HDN

3/8 HARDENED PLAIN WASHER

6шт.

5

492-11038

LOCK WASHER,3/8"

7шт.

6

425-106

NUT,3/8"-16, Cl 5

7шт.

7

113-252

BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5

2шт.

8

700116070

SPACER

4шт.

9

413-652

BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5

2шт.

10

700116065

SPACER

4шт.

11

D38346

BALL BEARING,10 mm ID x 30 mm OD x 9 mm

BEARING - cylindrical

4шт.

12

100-21118

SNAP RING,1.188", Int, #118

Ring, Snap, 1.188", Int, #118

4шт.

13

700127887

ARM

- clutch

4шт.

14

700126815

ROLLER

ASSEMBLY (Includes items 11 and 12)

4шт.

15

700116069

SPACER

1шт.
