Запчасти Case IH 8450 (058) - INDICATOR, BALE SIZE, ASSEMBLY (12) - MAIN FRAME

1

700115974

SUPPORT

- Switch

1шт.

2

700707234

BUTTON

Knob

1шт.

3

700115976

INDICATOR

1шт.

4

700115973

SPACER

3шт.

5

700115983

ANGLE

1шт.

6

700115988

LINK ASSY.

Link - Indicator

1шт.

7

1713155

FLAP

- Counter

1шт.

8

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

3/8 Hardened Plain Washer

1шт.

9

705525

WASHER

5/16 Hardened Plain Washer

1шт.

10

700115982

SUPPORT

Arm (S.N. CFH0015001 thru 0015274)

1шт.

11

700709602

WASHER,5/16"

5/16 Wide Plain Washer

2шт.

12

6605174

TUBE,19.05 mm OD, 35 mm Length

Spacer (S.N. CFH0015275 and on)

1шт.

703579

BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd

5/16-18 x 1 C

1шт.

7703945

BOLT,Hex, 5/16" - 18 x 2 1/2", Gr 5

5/16-18 x 2-1/2 C

1шт.

703249

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8-16 x 1 C

2шт.

7701188

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 x 1-1/4 C

1шт.

700013

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5

5/16-18 x 3/4 RHSNB

1шт.

7883325

BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M

5/16-18 x 3/4 HWHMS

6шт.

230-4215

NUT,5/16"-18, GA

5/16-18 HCLN

1шт.
