Запчасти Case IH 8450 (118) - GATHERING WHEEL KIT, SERIAL NUMBER CFH0015275 AND ON Pickup

HK50428

WHEEL

Gathering Wheel Kit Complete

1шт.

1

284463

SPACER

Bushing

2шт.

2

700117003

STRUT

- Wheel, Left

1шт.

3

700117013

STRAP

- Link

4шт.

4

700707651

SPRING

- Compression

4шт.

5

700117009

SPACER

Bushing

4шт.

6

700117011

SUPPORT

- Chain

2шт.

7

700116997

SPINDLE

Bracket - Spindle

2шт.

8

6868954

RIM

Wheel Assembly - Gathering

2шт.

9

50104

BEARING CUP,50.01mm OD

Cup - Bearing

4шт.

10

274760

SEAL KIT

7/8-14 Slotted Hex Nut

2шт.

11

7705429

WASHER,7/8", SAE

7/8 Narrow Plain Washer

2шт.

12

700708092

ROLLER BEARING

Cone - Bearing

4шт.

13

744912

SEAL

- Grease

2шт.

14

1714773

PIN,1/2" x 2", Coiled

4шт.

15

700117004

SLIDE

Strut - Wheel, Right

1шт.

16

8027476

SEGMENT

Notched Segment - Rubber

6шт.

17

700708977

SPRING

2шт.

18

700119167

ANGLE

- Bracket

2шт.

19

700117016

SUPPORT

- Pivot, Right

1шт.

20

705541

WASHER,0.53" ID x 1.06" OD x 0.14" Thk

1/2 Hardened Plain Washer

6шт.

21

26930

CAP

- Hub

2шт.

22

700117015

SUPPORT

- Pivot, Left

1шт.

23

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

3/8 Hardened Plain Washer

2шт.

702035

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd

3/8-16 x 1-1/4 C

2шт.

701235

BOLT,1/2" - 13 x 1 1/2", Gr 5

1/2-13 x 1-1/2 C

6шт.

7701683

BOLT,Hex, 5/8" - 11 x 3", Gr 5

5/8-11 x 3 C

2шт.

873562

BOLT,Hex, 1/2" - 13 x 7 1/2", Gr 5

1/2-13 x 7-1/2 B

4шт.

7770175

CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 1 1/4", Gr 5

1/4-20 x 1-1/4 RHSNB

24шт.

7883325

BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M

5/16-18 x 3/4 HWHMS

4шт.
