Запчасти Case IH 8450 (034) - GEARBOX AND TWINE THREADER ASSEMBLY Driveline

1

700707665

LARGE PLATE

Leaf - Spring

2шт.

2

700107980

ARM

- Threader, Twine

1шт.

The gear on the arm is complete and not 1/2 gear and there is a timing mark on the gear.

1шт.

3

700107985

SHAFT

Jackshaft - Gear (S.N. CFH0015001 thru 0015274)

1шт.

3

700118878

SHAFT

Jackshaft - Gear (S.N. CFH0015275 and on)

1шт.

4

740159

RING, SNAP

Ring - Retainer

2шт.

5

700107978

PLATE

1шт.

6

700107977

GUIDE

- Twine

2шт.

7

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, 1/4"-28 NPT x .54" lg

2шт.

8

52266

WASHER

1-1/4 x 14 Gauge Machinery Bushing

4шт.

9

52613

RING, SNAP

Ring - Retainer

2шт.

10

6500540

GEARBOX

1шт.

10

700709190

GEARBOX ASSY

Gearbox

1шт.

10

700710131

TRANSFER BOX

Gearbox (S.N. CFH0015897 and on)

1шт.

11

7751605

BREATHER

Vent - Breather

1шт.

12

846642

BUSHING

- Reducer

1шт.

13

700107974

INDICATOR

- Threader Arm

1шт.

14

6549869

SUPPORT

Bracket - Tension

2шт.

15

700107969

PLATE

Support - Pulley, Twine

1шт.

16

6869382

SPACER

1шт.

17

700116222

PULLEY ASSY.

Pulley - Feeder, Twine

1шт.

18

700707677

SPRING

- Compression

2шт.

19

7745003

GUIDE

- Twine

1шт.

20

766543

SCREW

5/16-18 Thread

1шт.

21

7741119

HOSE CLAMP

- Hose

2шт.

22

700707201

HOSE

- Flex

1шт.

23

700707402

BEARING, ROLLER, CYL,10 mm ID x 30 mm OD x 9 mm

Bearing - Cylindrical

1шт.

24

740514

BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L

- Oilite

2шт.

25

700707403

RING

- Retainer

1шт.

26

700118879

NUT

- Special (S.N. CFH0015767 and on)

1шт.

27

858183

SPRING

- Compression (S.N. CFH0015767 and on)

1шт.

28

700122575

BUTTON

- Nylon

1шт.

29

705517

WASHER

1/4 Hardened Plain Washer

2шт.

30

705525

WASHER

5/16 Hardened Plain Washer

2шт.

31

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

3/8 Hardened Plain Washer

1шт.

700707343

SCREW

1/4-20 x 5/8 C

2шт.

7773856

BOLT,Hex, 1/4" - 20 x 2 3/4", Gr 5

1/4-20 x 2-3/4 C

2шт.

413-520

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

5/16-18 x 1-1/4 C Shear Bolt

1шт.

703249

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8-16 x 1 C

2шт.

413-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

3/8-16 x 1-3/4 C

1шт.

7701188

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 x 1-1/4 C

4шт.

700864

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/4", Gr 5

3/8-16 x 2-1/4 RHSNB

1шт.

7883325

BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M

5/16-18 x 3/4 HWHMS

2шт.

7774839

LOCK NUT

1/4-20 HTLN

4шт.

231-4115

NUT,5/16"-18, GB

5/16-18 HTLN

3шт.
